MCQs in Engineering Mechanics Part 6

This is the Multiples Choice Questions Part 6 of the Series in Engineering Mechanics as one of the General Engineering and Applied Sciences (GEAS) topic. In Preparation for the ECE Board Exam make sure to expose yourself and familiarize in each and every questions compiled here taken from various sources including past Board Questions in General Engineering and Applied Sciences (GEAS), Engineering Mechanics Books, Journals and other Engineering Mechanics References.

Online Questions and Answers in Engineering Mechanics Series

Following is the list of multiple choice questions in this brand new series:

Engineering Mechanics MCQs
PART 1: MCQs from Number 1 – 50                        Answer key: PART I
PART 2: MCQs from Number 51 – 100                   Answer key: PART II
PART 3: MCQs from Number 101 – 150                 Answer key: PART III
PART 4: MCQs from Number 151 – 200                 Answer key: PART IV
PART 5: MCQs from Number 201 – 250                 Answer key: PART V
PART 6: MCQs from Number 251 – 300                 Answer key: PART VI
PART 7: MCQs from Number 301 – 350                 Answer key: PART VII
PART 8: MCQs from Number 351 – 400                 Answer key: PART VIII

Continue Practice Exam Test Questions Part VI of the Series

Choose the letter of the best answer in each questions.

251. Addition which is followed by the parallelogram law described by the figure.

  • a) resolution of the vector
  • b) addition of the vector
  • c) equilibrium equation for a particle
  • d) particle

252. An object with inertia but of negligible dimension.

  • a) resolution of the vector
  • b) addition of the vector
  • c) equilibrium equation for a particle
  • d) particle

253. A particle is in equilibrium if the resultant of all forces acting on the particle is equal to zero.

  • a) resolution of the vector
  • b) addition of the vector
  • c) equilibrium equation for a particle
  • d) particle

254. In a rectangular coordinate system the equilibrium equations can be represented by three scalar equations.

  • a) equilibrium equation in component form
  • b) free body diagram
  • c) string or cable
  • d) linear spring

255. A mechanical device that can only transmit a tensile force along itself.

  • a) equilibrium equation in component form
  • b) free body diagram
  • c) string or cable
  • d) linear spring

256. A mechanical device that can which exerts a force along its line of its action and proportional to its extension.

  • a) equilibrium equation in component form
  • b) free body diagram
  • c) string or cable
  • d) linear spring

257. The tension in the cable is the same on both sides of the pulley.

  • a) frictionless pulley
  • b) static equilibrium for a rigid body]
  • c) newton’s 3rd law
  • d) composite bodies and external source

258. Each action has a reaction equal in magnitude and opposite in direction.

  • a) frictionless pulley
  • b) static equilibrium for a rigid body]
  • c) newton’s 3rd law
  • d) composite bodies and external source

259. Forces and couples which are a result of interaction between one part of an object and another part of it will not appear in the free body diagram of the whole object.

  • a) frictionless pulley
  • b) static equilibrium for a rigid body
  • c) newton’s 3rd law
  • d) composite bodies and external source

260. Each force or couple putted on a free diagram represents a model of how a body is affected by its surroundings.

  • a) a two force member
  • b) a three force member
  • c) forces and couples of a free body
  • d) truss

261. It is a structure made of two force members all pin is connected to each other.

  • a) a two force member
  • b) a three force member
  • c) forces and couples of a free body
  • d) truss

262. A body which has forces applied onto it at only two points and no couples applied onto it at all.

  • a) a two force member
  • b) a three force member
  • c) forces and couples of a free body
  • d) truss

263. A body which has forces applied onto it at only three points and no couples applied onto it at all.

  • a) a two force member
  • b) a three force member
  • c) forces and couples of a free body
  • d) truss

264. This method uses the free body diagram of joints in the structure to determine the forces in each member.

  • a) method of joints
  • b) the method of sections
  • c) zero force member
  • d) a redundant joint

265. This method uses free body diagrams of sections of the truss to obtain unknown forces.

  • a) method of joints
  • b) the method of sections
  • c) zero force member
  • d) a redundant joint

266. Some members in the truss which cannot carry load.

  • a) method of joints
  • b) the method of sections
  • c) zero force member
  • d) a redundant joint

267. In the free diagram load is directly transmitted from each member to the one opposite without any interaction.

  • a) method of joints
  • b) the method of sections
  • c) zero force member
  • d) a redundant joint

268. this members must be removed from the truss,otherwise one will have a insufficient number of equations.

  • a) redundant members
  • b) mechanism
  • c) curved members
  • d) none of the above

269. Sometimes there is too much freedom in a structure, the following structure cannot carry load since it will collapse under the load.

  • a) redundant members
  • b) mechanism
  • c) curved members
  • d) none of the above

270. Two forces acting on a two force member are along the line connecting the two points on which the loads are applied.

  • a) redundant members
  • b) mechanism
  • c) curved members
  • d) none of the above

271. A general triangular object which is placed between two objects to either hold them in place or is used to move one relative to the other.

  • a) screw
  • b) self locking screw
  • c) frames
  • d) wedges

272. It is a combination of a two wedges obtain from the opening the helical treads..

  • a) screw
  • b) self locking screw
  • c) frames
  • d) wedges

273. If the lead angle is selected such that in the absence of a screwing moment.

  • a) screw
  • b) self locking screw
  • c) frames
  • d) wedges

274. Is the second moment of area around a given axis.

  • a) area moment of inertia
  • b) radius of gyration
  • c) parallel axis theorem
  • d) none of the above

275. Can be calculated if we have a rectangular coordinate system,one can define the area moment of inertial around the axis.

  • a) area moment of inertia
  • b) radius of gyration
  • c) parallel axis theorem
  • d) none of the above

276. It is the distance away from the axis that all the area can be concentrated to result in the same moment of inertia.

  • a) area moment of inertia
  • b) radius of gyration
  • c) parallel axis theorem
  • d) none of the above

277. The explicit form of the laws of mechanics depend on this and is used to reference the motions.

  • a) euler’s law
  • b) linear momentum of particle
  • c) linear momentum of a body
  • d) inertial frame

278. Law which governs the motion for a rigid body

  • a) euler’s law
  • b) linear momentum of particle
  • c) linear momentum of a body
  • d) inertial frame

279. For a single particle of mass its linear momentum by its mass times its velocity.

  • a) euler’s law
  • b) linear momentum of particle
  • c) linear momentum of a body
  • d) inertial frame

280. Is assumed to be the sum of the linear momentum of its particles.

  • a) euler’s law
  • b) linear momentum of particle
  • c) linear momentum of a body
  • d) inertial frame

281. For a particle of mass is defined as the moment of linear momentum around the point.

  • a) angular momentum of a rigid body
  • b) angular momentum of a particle
  • c) angular velocity
  • d) angular acceleration

282. A vector itself which has a magnitude equal to the rate of rotation.

  • a) angular momentum of a rigid body
  • b) angular momentum of a particle
  • c) angular velocity
  • d) angular acceleration

283. Is the rate of change of the angular velocity with respect to time.

  • a) angular momentum of a rigid body
  • b) angular momentum of a particle
  • c) angular velocity
  • d) angular acceleration

284. When two surface come into contact forces are applied by each other surface on the other.

  • a) friction force
  • b) kinetic friction
  • c) static friction
  • d) pending motion

285. The frictional forces that can result between two surfaces slide relative to each other.

  • a) friction force
  • b) kinetic friction
  • c) static friction
  • d) pending motion

286. The frictional forces that can result when two surfaces are sliding to each other is proportional to the normal force applied on the surface.

  • a) friction force
  • b) kinetic friction
  • c) static friction
  • d) pending motion

287. Refers to the state just before surfaces start to slip.

  • a) friction force
  • b) kinetic friction
  • c) static friction
  • d) pending motion

288. Is a method for predicting failure of a structure containing a crack.

  • a) fracture mechanics
  • b) continuum mechanics
  • c) deformation mechanics
  • d) fluid mechanics

289. The study of deformations typically in the elastic range.

  • a) fracture mechanics
  • b) continuum mechanics
  • c) deformation mechanics
  • d) fluid mechanics ans.c

290. It is the study on how fluids react to forces.

  • a) fracture mechanics
  • b) continuum mechanics
  • c) deformation mechanics
  • d) fluid mechanics

291. A method of applying mechanics that assumes all objects are continuous.

  • a) fracture mechanics
  • b) continuum mechanics
  • c) deformation mechanics
  • d) fluid mechanics

292. Under this condition the forces or vectors are transformed into a polygon.

  • a) directional condition
  • b) analytical condition
  • c) hydraulics
  • d) graphical condition

293. If three or more non-parallel forces or vectors are in equilibrium they must be concurrent.

  • a) directional condition
  • b) analytical condition
  • c) hydraulics
  • d) graphical condition

294. If forces or vectors are in equilibrium then it must satisfy the three static equations.

  • a) directional condition
  • b) analytical condition
  • c) hydraulics
  • d) graphical condition

295. It is the application of fluid mechanics in engineering.

  • a) directional condition
  • b) analytical condition
  • c) hydraulics
  • d) graphical condition

296. When the loading is uniformly distributed horizontally the cable is analyzed as.

  • a) parabolic cable
  • b) catenary
  • c) projectile
  • d) rotation

297. When the loading is distributed along the cable the cable is analyzed as

  • a) parabolic cable
  • b) catenary
  • c) projectile
  • d) rotation ans.b

298. Is one whose action is not confined to or associated with a unique line in space.

  • a) sliding vector
  • b) free vector
  • c) fixed vector
  • d) none of the above

299. Is one for which a unique line in space must be maintained along which the quantity acts.

  • a) sliding vector
  • b) free vector
  • c) fixed vector
  • d) none of the above

300. Is one which a unique point of application is specified and therefore the vector occupies a particular position in space.

  • a) sliding vector
  • b) free vector
  • c) fixed vector
  • d) none of the above

Complete List of MCQs in General Engineering and Applied Science per topic

DOWNLOAD PDF / PRINT
Print Friendly, PDF & Email
Help Me Makes a Difference!

P inoyBIX educates thousands of reviewers/students a day in preparation for their board examinations. Also provides professionals with materials for their lectures and practice exams. Help me go forward with the same spirit.

“Will you make a small $5 gift today?”

Add Comment

© 2014 PinoyBIX Engineering. © 2019 All Rights Reserved | How to Donate? | Follow me on Blogarama DMCA.com Protection Status
Do NOT follow this link or you will be banned from the site!

Math Solution

Advanced Math problem age work mixture digit motion Analytic Geometry 01 problem Analytic Geometry 02 problem clock variation progression misc Combination problem Differential Calculus 01 Problem Differential Calculus 02 Problem Differential Equations Problem Fundamentals in Algebra Fundamentals in Algebra Problem Integral Calculus problem Permutation problem Plane Geometry problem Plane Trigonometry problem Probability problem quadratic equation binomial theorem logarithms Solid Geometry problem Spherical Trigonometry problem System of Numbers Problem Venn Diagram Problem

Questions and Answers in Mathematics

Advanced Math Age Work Mixture Digit Motion Algebra and General Mathematics Analytic Geometry 01 Analytic Geometry 02 Calculus Clock Variation Progression Misc Differential Calculus 01 Differential Calculus 02 Differential Equations Engineering Mathematics Geometry Integral Calculus Plane Geometry Plane Trigonometry Probability and Statistics Quadratic Equation Binomial Theorem Logarithms Solid Geometry Spherical Trigonometry System of Numbers Trigonometry

video

Pre-board in Electronics Engineering

Pre-board in Electronics Engineering - Answers

Questions and Answers

Basic Television - Grob TV Boylestad Questions and Answers Computer Principles Electrical Circuit Electricity and Magnetism Fundamentals Electronic Circuits Floyd Questions and Answers Floyd Self-test Grob Questions and Answers Industrial Electronics Principles and Applications Malvino Questions and Answers Microelectronics Power Generators / Sources / Principles and Applications Solid State Devices Tests and Measurements Vacuum Tubes

Pre-board in Communications Engineering

Pre-board in Communications Engineering Pre-board in Communications Engineering - Answers

Questions and Answers

Acoustics Antennas Blake Questions and Answers Broadcasting and Cable TV System Digital Communication Networks Forouzan Frenzel Self-test Kennedy Questions and Answers Microwave Communications Miscellaneous Questions in Communications Modulation Navigational Aids and Radar Systems Noise Optical Fiber Communications Radiation and Wave Propagation Satellite Communications Transmission Fundamentals Wire and Wireless Communications

GEAS Solution

Dynamics problem Economics problem Physics problem Statics problem Strength problem Thermodynamics problem

Pre-board in GEAS

Questions and Answers in GEAS

Engineering Economics Engineering Laws and Ethics Engineering Management Engineering Materials Engineering Mechanics General Chemistry Physics Strength of Materials Thermodynamics
Online Tool: Electrical Charge Conversions
Online Tool: Electrical Charge Conversions
Online Tool: Color Code Conversions
Online Tool: Color Code Conversions
Online Tool: Weight Measurement Conversions
Online Tool: Weight Measurement Conversions
Online Tool: Temperature Measurement Conversions
Online Tool: Temperature Measurement Conversions
Consider Simple Act of Caring!: LIKE MY FB PAGE

Our app is now available on Google Play, Pinoybix Elex

Get it on Google Play
