#### Problem Statement: Electrical Engineering Professional Subjects

**Electrical Machines: AC Generators Problem Solving**

The winding of a 4-pole alternator having 36 slots and a coil span of 1 to 8 is short-pitched by _____ degrees.

A.ย 140

B.ย 80

C.ย 20

D.ย 40

#### Problem Answer:

The winding is short-pitched by **40 degrees**.
