This is the Multiple Choice Questions in Chapter 19: Television from the book Electronic Communication Systems by Roy Blake
See also: MCQ in Electronic Communication Systems by George Kennedy
Start Practice Exam Test Questions
Choose the letter of the best answer in each questions.
MULTIPLE CHOICE
1. NTSC stands for:
a. National Television Systems Commission
b. National Television Systems Committee
c. National Television Systems Council
d. Nippon Television Systems Commission
Answer: Option B
Solution:
2. The NTSC specification was drawn up by the:
a. FCC
b. IRE
c. EIA
d. IEEE
Answer: Option C
Solution:
3. RGB stands for:
a. Red-Green Burst
b. Red-Green Brightness
c. Red-Green Bandwidth
d. Red-Green-Blue
Answer: Option D
Solution:
4. The number of scan lines in an NTSC signal is:
a. 525
b. 625
c. 1024
d. 1250
Answer: Option A
Solution:
5. The number of NTSC frames sent per second is:
a. 25
b. 30
c. 50
d. 60
Answer: Option B
Solution:
6. The number of NTSC fields sent per second is:
a. 25
b. 30
c. 50
d. 60
Answer: Option D
Solution:
7. The aspect ratio of a standard TV receiver is:
a. 3 : 4
b. 4 : 3
c. 525 : 625
d. 625 : 525
Answer: Option B
Solution:
8. Luminance refers to:
a. brightness
b. contrast
c. chroma
d. raster
Answer: Option A
Solution:
9. Luminance is measured in:
a. foot-candles
b. lumins
c. IRE units
d. NTSC units
Answer: Option C
Solution:
10. The maximum luminance level is called:
a. max white
b. peak white
c. all white
d. whiter than white
Answer: Option B
Solution:
11. The blanking level corresponds to a luminance of:
a. white
b. black
c. whiter than white
d. blacker than black
Answer: Option B
Solution:
12. The sync pulse level corresponds to a luminance of:
a. white
b. black
c. whiter than white
d. blacker than black
Answer: Option D
Solution:
13. The vertical blanking pulse is serrated to:
a. maintain horizontal sync
b. maintain vertical sync
c. equalize the DC level
d. all of the above
Answer: Option A
Solution:
14. When measured in lines, horizontal resolution:
a. is greater than vertical resolution
b. is about the same as vertical resolution
c. is less than vertical resolution
d. horizontal resolution is not measured in lines
Answer: Option B
Solution:
15. The smallest picture element is called a:
a. dot
b. pic
c. pixel
d. none of the above
Answer: Option C
Solution:
16. In a color TV receiver, Y I Q refers to:
a. luminance signal, in-phase color component, quadrature phase color component
b. composite color signal, in-phase color component, quadrature phase color component
c. composite video signal, in-phase video component, quadrature video color component
d. a method of demodulating stereo sound
Answer: Option A
Solution:
17. Compared to the luminance signal, the horizontal resolution for color is:
a. much greater
b. about the same
c. much less
d. resolution does not apply to color
Answer: Option C
Solution:
18. The modulation used for the video signal in a standard NTSC color TV receiver is:
a. SSB
b. vestigial sideband AM
c. suppressed-carrier AM
d. FM
Answer: Option B
Solution:
19. The modulation used for the audio signal in a standard NTSC color TV receiver is:
a. SSB
b. vestigial sideband AM
c. suppressed-carrier AM
d. FM
Answer: Option D
Solution:
20. The modulation used for the chroma signal in a standard NTSC color TV receiver is:
a. SSB
b. vestigial sideband AM
c. suppressed-carrier AM
d. FM
Answer: Option C
Solution:
21. The function of the “color burst” is to:
a. detect the presence of a color video signal
b. regenerate the color sub-carrier
c. to synchronize the color demodulation line by line
d. all of the above
Answer: Option D
Solution:
22. SAP stands for:
a. separate audio program
b. separate audio pulse
c. sync amplitude pulse
d. sync audio pulse
Answer: Option A
Solution:
23. The horizontal output transformer is also called:
a. the isolation transformer
b. the video transformer
c. the flyback transformer
d. the yoke
Answer: Option C
Solution:
24. Compared to a monochrome CRT, the accelerating voltage on a color CRT is:
a. about the same
b. much higher
c. much lower
d. color CRTs use magnetic acceleration
Answer: Option B
Solution:
25. Deflection in CRTs used in TV receivers is done:
a. magnetically for both vertical and horizontal
b. electrostatically for both vertical and horizontal
c. electrostatically for vertical and magnetically for horizontal
d. magnetically for vertical and electrostatically for horizontal
Answer: Option A
Solution:
26. AFPC stands for:
a. allowed full picture chroma
b. automatic frequency and phase control
c. automatic frequency and picture control
d. none of the above
Answer: Option B
Solution:
COMPLETION
1. ____________________ is a conductive coating on both the inside and outside of the CRT in a TV.
Answer: Aquadag
Solution:
2. The ____________________ standard for TV has been in use since 1953.
Answer: NTSC
Solution:
3. Video systems form pictures by a ____________________ process.
Answer: scanning
Solution:
4. During the horizontal blanking interval, the electron beam ____________________ from right to left.
Answer: retraces
Solution:
5. The NTSC specifies a ____________________ video signal.
Answer: composite
Solution:
6. The ____________________ ratio of a CRT screen is the ratio of width to height.
Answer: aspect
Solution:
7. Brightness information is called ____________________.
Answer:
luma
luminance
Solution:
8. Color information is called ____________________.
Answer:
chroma
chrominance
Solution:
9. The blanking period before the sync pulse is called the front ____________________.
Answer: porch
Solution:
10. Odd and even fields are identified by the ____________________ of the vertical sync pulse.
Answer: position
Solution:
11. Each horizontal scan line takes ____________________ microseconds, not including blanking.
Answer: 62.5
Solution:
12. Horizontal blanking lasts ____________________ microseconds.
Answer: 10
Solution:
13. Vertical blanking lasts about ____________________ milliseconds.
Answer: 1.3
Solution:
14. Picture elements are called ____________________.
Answer: pixels
Solution:
15. The maximum number of scan lines under NTSC is ____________________.
Answer: 525
Solution:
16. The human eye is most sensitive to the color ____________________.
Answer: green
Solution:
17. The color sub-carrier frequency is approximately ____________________ MHz.
Answer: 3.58
Solution:
18. SAP stands for ____________________ audio program.
Answer: separate
Solution:
19. The second anode of a CRT is often called the ____________________.
Answer: ultor
Solution:
20. The accelerating voltage for a color CRT is about ____________________ kV.
Answer: 20 to 30
Solution:
21. The inside of a CRT’s face-plate is coated with ____________________ to generate the picture.
Answer: phospor
Solution:
22. The horizontal output transformer is called the ____________________ transformer.
Answer: flyback
Solution:
23. A good way to separate luma from chroma is to use a ____________________ filter.
Answer: comb
Solution:
24. The color ____________________ turns off the color circuitry when a color TV is receiving a monochrome signal.
Answer: killer
Solution:
25. Signal levels in cable TV systems are usually measured in ____________________.
Answer: dbmV
Solution:
26. The antenna for a CATV system is located at the ____________________ end.
Answer: head
Solution:
27. A ____________________ shows a color-bar signal with predetermined levels and phases.
Answer: vectorscope
Solution:
28. Color intensity is called ____________________.
Answer: saturation
Solution:
29. The ____________________ of the chroma signal represents the color hue.
Answer: phase
Solution:
30. The ____________________ controls in a color TV adjust the electron beams to strike the correct color phosphor dots.
Answer: purity
Solution:
31. The ____________________ controls in a color TV adjust the electron beams to strike the correct triad of phosphor dots.
Answer: convergence
Solution:
