Blake: MCQ in Terrestrial Microwave Communication Systems

This is the Multiple Choice Questions in Chapter 17: Terrestrial Microwave Communication Systems from the book Electronic Communication Systems by Roy BlakeBlake: MCQ in Terrestrial Microwave Communication Systems. If you are looking for a reviewer in Communications Engineering this will definitely help. I can assure you that this will be a great help in reviewing the book in preparation for your Board Exam. Make sure to familiarize each and every questions to increase the chance of passing the ECE Board Exam.

See also: MCQ in Electronic Communication Systems by George Kennedy

Start Practice Exam Test Questions

Choose the letter of the best answer in each questions.

MULTIPLE CHOICE

1. Another term for a single microwave link is a:

a. section

b. hop

c. skip

d. jump

View Answer:

Answer: Option B

Solution:

2. Microwave systems use:

a. FM

b. SSB

c. QAM

d. all of the above

View Answer:

Answer: Option D

Solution:

3. The typical reliability of a microwave system is:

a. 90%

b. 99%

c. 99.9%

d. 99.99%

View Answer:

Answer: Option D

Solution:

4. A typical microwave system uses a transmitted power of about:

a. 2 watts

b. 20 watts

c. 200 watts

d. none of the above

View Answer:

Answer: Option A

Solution:

5. In analog microwave systems, additional repeaters increase the:

a. reliability

b. noise level

c. jitter

d. all of the above

View Answer:

Answer: Option B

Solution:

6. In digital microwave systems, additional repeaters increase the:

a. reliability

b. noise level

c. jitter

d. all of the above

View Answer:

Answer: Option C

Solution:

7. LOS stands for:

a. Loss Of Skip

b. Loss Of Signal

c. Line-Of-Sight

d. Line-Of-Signal

View Answer:

Answer: Option C

Solution:

8. Too much antenna gain causes:

a. a very narrow microwave beam

b. a very wide microwave beam

c. excessive noise

d. jitter

View Answer:

Answer: Option A

Solution:

9. The microwave signal path should clear obstacles by at least:

a. 60% of the Faraday zone

b. 60% of the Fresnel zone

c. 60% of the height of the antenna tower

d. 60% of the highest obstacle height

View Answer:

Answer: Option B

Solution:

10. Satisfactory performance of an analog microwave system is defined as:

a. a carrier-to-noise ratio that exceeds a given value

b. an ERP level that exceeds a given value

c. an energy-per-hertz level that exceeds a given value

d. none of the above

View Answer:

Answer: Option A

Solution:

11. Satisfactory performance of a digital microwave system requires a:

a. low level of transmitted power

b. high level of ERP

c. good energy per bit per transmitted Watt ratio

d. good energy per bit per noise density ratio

View Answer:

Answer: Option D

Solution:

12. Fading is caused by:

a. multipath reception

b. attenuation due to weather

c. ducting

d. all of the above

View Answer:

Answer: Option D

Solution:

13. The effects of fading due to multipath reception are often reduced using:

a. diversity

b. power

c. high-gain antennas

d. all of the above

View Answer:

Answer: Option A

Solution:

14. Repeaters are used in a microwave system:

a. always

b. when distance exceeds line-of-sight

c. above 10 GHz

d. below 10 GHz

View Answer:

Answer: Option B

Solution:

15. Microwave repeaters can be:

a. IF type

b. baseband type

c. regenerative type

d. all of the above

View Answer:

Answer: Option D

Solution:

16. An advantage of digital techniques over analog in a microwave system is:

a. less bandwidth is required

b. accumulation of noise is reduced

c. it requires less power

d. all of the above

View Answer:

Answer: Option B

Solution:

17. MMDS stands for:

a. Multichannel Microwave Distribution System

b. Multipoint Microwave Distribution System

c. Multichannel Multipoint Distribution System

d. Multiple Microwave Distribution Systems

View Answer:

Answer: Option C

Solution:

18. LMDS stands for:

a. Local Microwave Distribution System

b. Local Multipoint Distribution System

c. Local Multichannel Distribution System

d. Low-power Microwave Distribution System

View Answer:

Answer: Option B

Solution:

19. LMDS is:

a. bidirectional

b. unidirectional

c. multidirectional

d. none of the above

View Answer:

Answer: Option A

Solution:

COMPLETION

1. One microwave link is called a ____________________.

View Answer:

Answer: hop

Solution:

2. STL stands for ____________________-to-transmitter links.

View Answer:

Answer: studio

Solution:

3. A typical microwave system has about one hour per ____________________ or less of downtime.

View Answer:

Answer: year

Solution:

4. Adding more links causes ____________________ in a digital microwave system.

View Answer:

Answer: jitter

Solution:

5. In microwave systems, it is more convenient to use noise ____________________ than noise figure in calculations.

View Answer:

Answer: temperature

Solution:

6. In digital microwave systems, the energy per bit per ____________________ is a key parameter.

View Answer:

Answer: noise density

Solution:

7. Multipath reception can cause 20 dB or more of ____________________.

View Answer:

Answer: fading

Solution:

8. Two antennas stacked one above the other on a tower is an example of ____________________ diversity in a microwave system.

View Answer:

Answer: space

Solution:

9. The ability to use two frequencies simultaneously is an example of ____________________.

View Answer:

Answer: diversity

Solution:

10. Microwave systems generally use less than ____________________ watts of power.

View Answer:

Answer: ten

Solution:

11. ____________________ are necessary in a microwave system that extends beyond the line-of-sight distance.

View Answer:

Answer: Repeaters

Solution:

12. Analog microwave systems use both IF and ____________________ repeaters.

View Answer:

Answer: baseband

Solution:

13. Microwave digital radio techniques reduce the accumulation of ____________________ as a signal goes from link to link.

View Answer:

Answer: noise

Solution:

14. MMDS is unidirectional, but ____________________ is bidirectional.

View Answer:

Answer: LMDS

Solution:

SHORT ANSWER

1. If the line-of-sight distance for an optical beam is 12 km, what would it be, approximately, for a microwave beam?

View Answer:

Answer: 16 km

Solution:

2. A line-of-sight microwave link operating at 4 GHz has a separation of 40 km between antennas. An obstacle in the path is located midway between the two antennas. By how much must the beam clear the obstacle?

View Answer:

Answer: 16.4 meters

Solution:

3. A transmitter and receiver operating at 1 GHz are separated by 10 km. How many dBm of power gets to the receiver if the transmitter puts out 1 Watt, and both the sending and receiving antennas have a gain of 20 dBi?

View Answer:

Answer: -42.4 dBm

Solution:

ANS:

4. A microwave system has a feed-line loss of 2 dB and sees a sky temperature of 150 K. Calculate the noise temperature of the antenna/feed-line system referenced to the receiver input.

View Answer:

Answer: 201 K

Solution:

5. A microwave receiver receives –60 dBm of signal. The noise power is –100 dBm. What is the carrier-to-noise power ratio?

View Answer:

Answer: 40 dB

Solution:
