MCQs in Transistor Biasing

This is the Multiple Choice Questions in Chapter 8: Transistor Biasing from the book Electronic Principles 7th Edition by Albert Malvino. If you are looking for a reviewer in Electronics Engineering this will definitely help. I can assure you that this will be a great help in reviewing the book in preparation for your Board Exam. Make sure to familiarize each and every questions to increase the chance of passing the ECE Board Exam.

Topic Outline

  • MCQs in Voltage Divider Bias
  • MCQs in Accurate VDB Analysis
  • MCQs in Two-Supply Emitter Bias
  • MCQs in Other types of Bias
  • MCQs in PNP Transistor

Start Practice Exam Test Questions

Choose the letter of the best answer in each questions.

1. For emitter bias, the voltage across the emitter resistor is the same as the voltage between the emitter and the

  • a. Base
  • b. Collector
  • c. Emitter
  • d. Ground

2. For emitter bias, the voltage at the emitter is 0.7 V less than the

  • a. Base voltage
  • b. Emitter voltage
  • c. Collector voltage
  • d. Ground voltage

3. With voltage-divider bias, the base voltage is

  • a. Less than the base supply voltage
  • b. Equal to the base supply voltage
  • c. Greater than the base supply voltage
  • d. Greater than the collector supply voltage

4. VDB is noted for its

  • a. Unstable collector voltage
  • b. Varying emitter current
  • c. Large base current
  • d. Stable Q point

5. With VDB, an increase in emitter resistance will

  • a. Decrease the emitter voltage
  • b. Decrease the collector voltage
  • c. Increase the emitter voltage
  • d. Decrease the emitter current

6. VDB has a stable Q point like

  • a. Base bias
  • b. Emitter bias
  • c. Collector-feedback bias
  • d. Emitter-feedback bias

7. VDB needs

  • a. Only three resistors
  • b. Only one supply
  • c. Precision resistors
  • d. More resistors to work better

8. VDB normally operates in the

  • a. Active region
  • b. Cutoff region
  • c. Saturation region
  • d. Breakdown region

9. The collector voltage of a VDB circuit is not sensitive to changes in the

  • a. Supply voltage
  • b. Emitter resistance
  • c. Current gain
  • d. Collector resistance

10. If the emitter resistance increases in a VDB circuit, the collector voltage

  • a. Decreases
  • b. Stays the same
  • c. Increases
  • d. Doubles

11. Base bias is associated with

  • a. Amplifiers
  • b. Switching circuits
  • c. Stable Q point
  • d. Fixed emitter current

12. If the emitter resistance doubles in a VDB circuit, the collector current will

  • a. Double
  • b. Drop in half
  • c. Remain the same
  • d. Increase

13. If the collector resistance increases in a VDB circuit, the collector voltage will

  • a. Decrease
  • b. Stay the same
  • c. Increase
  • d. Double

14. The Q point of a VDB circuit is

  • a. Hypersensitive to changes in current gain
  • b. Somewhat sensitive to changes in current gain
  • c. Almost totally insensitive to changes in current gain
  • d. Greatly affected by temperature changes

15. The base voltage of two supply emitter bias (TSEB) is

  • a. 0.7 V
  • b. Very large
  • c. Near 0 V
  • d. 1.3 V

16. If the emitter resistance doubles with TSEB, the collector current will

  • a. Drop in half
  • b. Stay the same
  • c. Double
  • d. Increase

17. If a splash of solder shorts the collector resistor of TSEB, the collector voltage will

  • a. Drop to zero
  • b. Equal the collector supply voltage
  • C. Stay the same
  • d. Double

18. If the emitter resistance increases with TSEB, the collector voltage will

  • a. Decrease
  • b. Stay the same
  • C. Increase
  • d. Equal the collector supply voltage

19. If the emitter resistor opens with TSEB, the collector voltage will

  • a. Decrease
  • b. Stay the same
  • c. Increase slightly
  • d. Equal the collector supply voltage

20. In TSEB, the base current must be very

  • a. Small
  • b. Large
  • c. Unstable
  • d. Stable

21. The Q point of TSEB does not depend on the

  • a. Emitter resistance
  • b. Collector resistance
  • c. Current gain
  • d. Emitter voltage

22. The majority carriers in the emitter of a PNP transistor are

  • a. Holes
  • b. Free electrons
  • c. Trivalent atoms
  • d. Pentavalent atoms

23. The current gain of a PNP transistor is

  • a. The negative of the NPN current gain
  • b. The collector current divided by the emitter current
  • c. Near zero
  • d. The ratio of collector current to base current

24. Which is the largest current in a PNP transistor?

  • a. Base current
  • b. Emitter current
  • c. Collector current
  • d. None of these

25. The currents of a PNP transistor are

  • a. Usually smaller than NPN currents
  • b. Opposite NPN currents
  • c. Usually larger than NPN currents
  • d. Negative

26. With PNP voltage-divider bias, you must use

  • a. Negative power supplies
  • b. Positive power supplies
  • c. Resistors
  • d. Grounds

Check your work.
