Chapter 21: Introduction to Data Communications and Networking

This is the summary notes of the important terms and concepts in Chapter 21 of the book "Electronic Communications System" by Wayne Tomasi. The notes are properly synchronized and concise for much better understanding of the book. Make sure to familiarize this review notes to increase the chance of passing the ECE Board Exam.


CHAPTER 21

INTRODUCTION TO DATA
COMMUNICATIONS AND NETWORKING


Items

Definitions

Terms

1

Information that is stored in digital form. Information that
has been processed organized and stored.

Data

2

Knowledge or intelligence.

Information

3

The transmission, reception, and processing of digital
information.

Data Communications

4

It is to transfer digital information from one place to
another.

Data Communications Circuit

5

A set of devices interconnected by media links.

Network

6

Systems of interrelated computers and computer equipment and
can be as simple as a personal computer connected together through the PTN.

Data Communications Networks

7

Automatic teller machine

ATM

8

When was one of the earliest means of communicating
electrically coded information occurred?

1753

9

In 1833, he developed an unusual system based on a
five-by-five matrix representing 25 letters. The idea was to send message
over a single wire.

Carl Friedrich Gauss

10

The first successful data communications that was invented in
1832. Dots and Dashes.

Telegraph

11

He invented the first practical data communications code which
is called Morse Code.

Samuel F.B. Morse

12

Allegedly invented the first telegraph in England.

1. Sir Charles Wheatstone
2. Sir William Cooke

13

In 1874, he invented the telegraph multiplexer which Emile
allowed up to six different telegraph machines to be transmitted
simultaneously over a single wire.

Emile Baudot

14

It was invented in 1875 by Alexander Graham Bell.

Telephone

15

He succeeded in sending radio telegraph messages.

Guglielmo Marconi

16

The only means of sending information across large spans of
water until 1920.

Telegraph

17

A German engineer, demonstrated a computing machine sometime
in the late 1930s.

Konrad Zuis

18

Developed the ENIAC computer on Feb. 14, 1946

J. Presper Eckert
John Mauchley

19

A technique that process one job at a time.

Batch Processing

20

Built in 1951 by Remington Rand Corp., was the First
mass-produced electronic computer.

UNIVAC Computer

21

A public data communications network used by millions of
people all over the world to exchange business and personal information.

Internet

22

Private data communications networks used by many companies to
exchange information among employees and resources.

Intranet

23

Any system of computers, computer terminals or computer
peripheral equipment used to transmit and receive information between two or more
locations.

Data Communications Network

24

A set of equipment, transmission media and procedures that
ensures that a specific sequence of events occurs in a network in the proper
order to produce the intended results.

Network Architecture

25

Messages are intended for all subscribers on the network.

Broadcasting

26

Messages are intended for a specific group of subscribers.

Multicasting

27

Defines the procedures that the systems involved in the
communications process will use.

Protocols

28

Sets of rules governing the orderly exchange of data within
the network or a portion of the network.

Data Communications Protocols

29

The list of the protocols used by a system.

Protocol Stack

30

It consists of two or more independent levels.

Layered Network
Architecture

31

A logical connection is established between the endpoints
prior to the transmission of data.

Connection Oriented or Connectionless

32

They are designed to provide a high degree of reliability for
data moving through the network.

Connection-Oriented Protocol

33

A connection process that occurs between two stations before
any data are actually transmitted.
Another terms:
·
Sessions

·
Virtual
circuits
·
logical
connections


Handshake

34

It refers to the structure or format of the data within the
message, which includes the sequence in which the data are sent.

Syntax

35

Guidelines that have been generally accepted by the data
communications industry.
Types of standards:
Ø Proprietary system -open
Ø open system

Data Communications Standards

36

Generally controlled and manufactured by one company.

Proprietary Standard

37

The international organization for standardization on a wide
range of subjects.

International Standards
Organization (ISO)

38

The member of ISO from the United States.

American National Standard Institute
(ANSI)

39

It is formerly CCITT, one of four permanent parts is based in
Geneva, Switzerland.

International Telecommunications Union

40

Modem interfaces and data transmission over the telephone
lines.

V series

41

Data transmission over public digital Network, e-mail and
directory services.

X series

42

An international professional organization founded in the
United States and is comprised of electronics, computer and communications
engineers.

Institute of Electrical & IEEE)and
Electronics Engineers

43

A non-profit U.S. trade association that establishes and
recommends industrial standards.

Electronics Industry Association
(EIA)

44

The leading trade association in the communications and
information technology industry.

Telecommunications Industry Association

45

The research arm of the Department of Defense in 1957.

Advanced Research Projects Agency
(ARPA)

46

A large international community of network designers,
operators, vendors and researches concerned with the evolution of the
internet architecture and the smooth operation of the internet.

Internet Engineering Task Force
(IETF)

47

It promotes research of importance to the evolution of the
future Internet by creating focused, long term and small research groups
working on topics related to internet protocols.

Internet Research Task Force
 (IRTF)

48

A unit of data.

Protocol data Unit
(PDU)

49

The process of adding and removing the PDU information.

Encapsulation/Decapsulation

50

It means to place in a capsule or other protected environment.

Encapsulate

51

It means to remove from a capsule or other protected
environment.

Decapsulate

52

Defines which entity the service is intended.

Service Access Point
(SAP)

53

The name for the set of standards for communicating among
computers
Seven OSI layers:
·
application

·
presentation

·
session

·
transport

·
network

·
data
link
·
physical


Open Systems Interconnection
(OSI)

54

Responsible for the actual propagation of unstructured data
bits through a transmission medium.

Physical Layer

55

Responsible for providing error-free communications across the
physical link connecting primary and secondary stations within a network.

Data Link Layer

56

Provides details that enable data to be routed between devices
in an environment using multiple networks, subnetwork, or both.

Network Layer

57

Controls and ensures the end-to-end integrity of the data
message propagated through the network between two devices, which provides
reliable, transparent transfer of data between two endpoints.

Transport Layer

58

Responsible for network availability.

Session Layer

59

Provides independence to the application processes by
addressing any code or syntax conversion necessary to present the data to the
network in a common communications format.

Presentation Layer

60

It provides distributed information services and controls the
sequence of activities within an application.

Application Layer

61

An endpoint where subscribers gain access to the circuit.

Station

62

Another term of station which is the location of computers,
computer terminals, workstations and other digital computing equipment.

Node

63

Interconnects digital computer equipment.

Facilities

64

Provides means to enter data from humans.

Source

65

Encodes a wireless radio system without being converted to
analog first.

Transmitter

66

Carries the encoded signals from the transmitter to the
receiver.

Transmission Medium

67

Converts the encoded signals received from the transmission
medium back to their original form.

Receiver

68

It could be a mainframe computer, personal computer
workstation or virtually any piece of digital equipment.

Destination

69

A type of transmission where all four bits can be transmitted
simultaneously during the time of a single clock pulse.

Parallel by Bit or Serial by Character

70

Transmission where four clock pulses are required to transmit
the entire four-bit code.

Serial by Bit

71

It involves only two locations or stations

Two-Point  Configuration

72

It involves three or more stations.

Multi-point Configuration

73

Data transmission is unidirectional where information can be
sent in only one direction.

Simplex

74

Also called Receive-Only, Transmit Only or One-way-only Lines

Simplex Lines

75

Data transmission is possible in both directions but not at
the same time.
Another term:
·
two
way alternate lines
·
either
way lines

Half Duplex

76

Transmissions are possible in both directions between two
stations simultaneously, but they must be between same time.
Another terms;
·
Two-way
simultaneous
·
duplex

·
both-way
lines


Full Duplex

77

Transmission is possible in both directions at the same time
but not between the same two stations. It is possible only on multipoint
circuits.

Full/Full Duplex

78

The process of sharing resources between computers over a data
communications network.

Networking

79

The manual technique of moving data on disks.

Sneaker Net

80

Computers that hold shared files, programs and the network
operating system.

Servers

81

Computers that access and use the network and shared network
resources.

Client

82

The facilities used to interconnect computers in a network.

Transmission Media

83

Data that file servers provide to clients.

Shared Data

84

Hardware resources provided to the users of the network by
servers.

Shared Printers and
other
peripherals

85

An expansion card and prepares and sends data, receives data
and controls data flow between the computer and the network.

Network Interface Card
(NIC)

86

Allows personal computers to access files, print to a local
printer and have and use one or more disk and CD drives that are located on
the computer.

Local Operating System
(LOS)

87

A program that runs on computers and servers that allows the
computers to communicate over a network.

Network Operating
System (NOS)

88

One in which all computers share their resources.

Peer – to – Peer Client/
Server Network

89

One computer is designated the server and the rest of the
computers are clients.

Dedicated Client/Server Network

90

Describes the layout or appearance of a network.

Network Topology

91

Describes how the network is actually laid out.

Physical Topology

92

Describes how data actually flow through the network.

Logical Topology

93

A multipoint data communications network where remote stations
are connected by cable segments directly to a central located computer.

Star Topology

94

A multipoint data communications circuit that makes it
relatively simple to control data flow between and among the computers.

Bus Topology

95

A multipoint data communications network where all stations
are interconnected in tandem to form a closed loop or circle.

Ring Topology

96

Every station has a direct two-point communications link to
every other station on the circuit.

Mesh Topology

97

Combining two or more of the traditional topologies to form a
larger, more complex topology.

Hybrid Topology

98

Privately own networks in which 10 to 40 compute share data
resources with one or more file server.

Local Area Networks
(LANs)

99

A high-speed network similar to a LAN except the are designed
to encompass larger areas, usually that of an entire city.

Metropolitan Area Networks
 (MANs)

100

Provides low-speed, long distance transmission of data voice,
and video information over large and widely dispersed geographical areas such
as country or an entire continent. It interconnects cities or states.

Wide Area Network
(WAN)

101

Bit rate of WANs.

1.5 Mbps-2.4 Gbps

102

Provides connects between countries around the entire globe.

Global Area Network
(GANs)

103

A network connection that normally carries traffic between
departmental LANs within a single company.

Building Backbone

104

A network connection used to carry traffic to and from LANs
located in various buildings on campus.

Campus Backbone

105

Developed by Department of Defense, comprise of several
interactive modules that provide specific functionality.

TCP/IP Protocol Suite

106

The network layer of TCP/IP.

Internet layer/
Internet work Layer

107

Transport layer of TCP/IP.

Transmission Control Protocol
(TCP)
User datagram Protocol
(UDP)

108

Provides a means of physically delivering data packets using
frames or cells.

Network Access Layer

109

Contains information that pertains to how data can be routed
through the network.

Internet Layer

110

Services the process and internet layers to handle the
reliability and session aspects of data transmission.

Host-to-Host Layer

111

Provides applications support.

Process Layer

112

Defines a three layer logical hierarchy that specifies where
things belong, how they fit together and what functions go where.
Three layers:
·
Core
layer
·
Distribution
layer
·
access
layer

Cisco Three-Layer Model

113

The core of the network as it resides at the top of the
hierarchy and is responsible for transporting large amounts of data traffic
reliably and quickly.

Core Layer

114

The communications point between the access and the core layer
that provides routing, filtering, WAN access and how data packets are allowed
to access the core layer.

Distribution Layer

115

Another term for Distribution layer.

Workgroup Layer

116

Controls workgroup and individual user access to
internetworking resources.

Access Layer

117

Another term for Access layer.

Desktop Layer

Complete List of Reviewers in Electronic Communications System per Chapter

Important List of Communications Engineering Materials

Chapter 21: Introduction to Data Communications and Networking – Review Notes
Rate this:

Add Comment

© 2017 PinoyBIX Engineering. © 2017 All Rights Reserved | Donate
Basic Television – Grob TV Chapter Exercises
Series of Multiple Choice Questions in Engineering Mathematics
Complete Practice Quiz in Electronic Devices and Circuit Theory
Complete Practice Quiz in Data Communications and Networking
Online Tool: Color Code Conversions
Online Tool: Weight Measurement Conversions
Online Tool: Temperature Measurement Conversions
Online Tool: Length Measurement Conversions

Get FREE Review Course
in your inbox

Subscribe to our mailing list and get reviewers and updates to your email inbox.

Thank you for subscribing.

Something went wrong.
