Communications Engineering Mastery Test 19: ECE Pre-Board

This is 100 items Practice Examinations set 19 in Communications Engineering (Electronics Systems and Technology) composed of previous Board Exams Questions. Read each questions and choices carefully! Choose the best answer. In the actual board, you have to answer 100 items in Communications Engineering within 5 hours. You have to get at least 70% to pass the subject. Communications Engineering is 30% of the total 100% Board Rating along with Mathematics (20%), General Engineering and Applied Sciences (20%) and Electronics Engineering (30%). Familiarize each and every questions to increase the chance of passing the ECE Board Examination.

Start the Test Yourself Exam 19

Communications Engineering Mastery Test 18: ECE Pre-Board

Choose the letter of the best answer in each questions.

1. Spacing bias distortion results in ________.

a) Space being lengthened and marks being shortened

b) Space being shortened and marks being lengthened

c) Space being lengthened but marks being unaffected

d) Extra spaces being printed on the teletypewriter

View Answer:

Answer: Option A

Solution:

2. How much acoustic power must a public address system be able to put out in order to create an SPL of 100 dB for a musical show in the 10,000 cubic meter auditorium?

a) 30 mW

b) 200 W

c) 33 W

d) 80 W

View Answer:

Answer: Option C

Solution:

3. What is the IF range of a satellite TV receiver?

a) 950 to 1450 MHz

b) 3.7 to 4.2 GHz

c) 13.7 to 14.2 GHz

d) 40 to 42 MHz

View Answer:

Answer: Option A

Solution:

4. _____ is the range of quietness to loudness.

a) Static Range

b) Dynamic Range

c) Flat Response

d) Active Response

View Answer:

Answer: Option B

Solution:

5. An AC transmission path has the characteristics of _________.

a) A Low-Pass Filter

b) A High-Pass Filter

c) A band-pass Filter

d) Both (a) and (b)

View Answer:

Answer: Option C

Solution:

6. Any unwanted form of energy tending to interfere with the proper and easy reception of wanted signals

a) Noise

b) Sound Wave

c) Electrical Energy

d) Radio Wave

View Answer:

Answer: Option A

Solution:

7. In a Yagi antenna __________.

a) The director is shorter than the driven element

b) The elements are spaced at least one wavelength apart

c) The reflectors are shorter than the driven element

d) There are usually more reflector than directors

View Answer:

Answer: Option A

Solution:

8. The main purpose of modulation is to_______.

a) Combine two waves of different frequencies

b) Achieve wave-shaping of the carrier wave

c) All of these

d) Transmit low frequency information over long distances efficiently

View Answer:

Answer: Option D

Solution:

9. The data transmission rate of a modem is measured in ______.

a) Bytes Per Second

b) Baud Rate

c) Bits Per Second

d) Megahertz

View Answer:

Answer: Option B

Solution:

10. Demodulation

a) Is performed at the transmitting station

b) Removes Sidebands

c) Rectifies Modulated Signal

d) Is Opposite of Modulation

View Answer:

Answer: Option D

Solution:

11. The standard ASCII ______.

a) Is version II of the ASC standard

b) Has 128 characters including 32 control characters

c) Is a subset of the 8-bit EBCDIC code

d) Is used only in the US and Canada

View Answer:

Answer: Option B

Solution:

12. In amplitude modulation _____.

a) Carrier Frequency is Changed

b) Carrier Amplitude is Changed

c) Three Sidebands are Produced

d) Fidelity is Improved

View Answer:

Answer: Option B

Solution:

13. Which is not an example of data communications?

a) A teletype printing news bulletins

b) A computer transmitting files to another computer

c) An automatic teller machine checking account balances with the bank’s computer

d) A salesman telephoning orders to the office

View Answer:

Answer: Option D

Solution:

14. _____ is a noise created outside the receiver.

a) Internal Noise

b) External Noise

c) Shot Noise

d) Industrial Noise

View Answer:

Answer: Option B

Solution:

15. The corrections and accuracy of the transmitted message content is ________.

a) Verified by the Modem

b) Determined by the sender and receiver, not by the communications system

c) Ensured by the use of digital techniques

d) Both (a) and (c)

View Answer:

Answer: Option B

Solution:

16. How many dB can a moderately vigorous speaking voice of Luciano Pavarotti, produce acoustic power of 0.100 microwatts with a room volume of 100 cubic meters, with reverberation time of 1.2 seconds?

a) 75 dB

b) 60 dB

c) 25 dB

d) 100 dB

View Answer:

Answer: Option A

Solution:

17. Two-state (binary) communications system are better because:

a) They can interface directly with the analog telephone networks

b) People think better in binary

c) The components are simpler, less costly and more reliable

d) Interstate calls are less costly

View Answer:

Answer: Option C

Solution:

18. One hundred percent modulation is produced in AM when carrier

a) Frequency equals Signal Frequency

b) Frequency exceeds Signal Frequency

c) Amplitude equals Signal Amplitude

d) Amplitude exceeds Signal Amplitude

View Answer:

Answer: Option C

Solution:

19. The difference between timing and framing is _____.

a) Timing is concerned with the individual bits, framing is concerned with the boundaries between characters

b) Timing is concerned primarily with asynchronous systems, framing is concerned of synchronous system

c) Timing refers to serial transmission, framing refers to parallel

d) Both (b) and (c)

View Answer:

Answer: Option A

Solution:

20. ________ is a noise created by man.

a) Solar Noise

b) Industrial Noise

c) Extraterrestrial Noise

d) Galactic Noise

View Answer:

Answer: Option B

Solution:

21. Which of the following statements about flat unpaired cable is not correct? Flat cable

a) Is effective in cramped locations where round cable will not easily fit

b) Has poor immunity to noise induced by sources outside the cable

c) None of these

d) Has good adjacent pair noise immunity

View Answer:

Answer: Option D

Solution:

22. For a given carrier wave, maximum undistorted power is transmitted when value of modulation is _____.

a) 1

b) 0.8

c) 0.5

d) 0

View Answer:

Answer: Option A

Solution:

23. Asynchronous transmission ___________.

a) Is less efficient than synchronous, but simpler

b) Is much faster than synchronous transmission

c) Are used in asynchronous and synchronous systems, respectively

d) Both (b) and (c)

View Answer:

Answer: Option A

Solution:

24. In an AM wave with 100% modulation, each sideband carries ______ of the total transmitted power.

a) One-half

b) One-sixth

c) One-third

d) Two-thirds

View Answer:

Answer: Option B

Solution:

25. What is the relationship between possible bandwidth and signal frequency?

a) As bandwidth decreases, signal frequency decreases

b) As signal frequency increases, bandwidth increases

c) As signal frequency increases, bandwidth decreases

d) They are not related

View Answer:

Answer: Option B

Solution:

26. An average human conversation has an average Sound Pressure Level (SPL) of ____ dB.

a) 0

b) 40

c) 100

d) 60

View Answer:

Answer: Option D

Solution:

27. The amount of uncertainty in a system of symbols is also called _____.

a) Bandwidth

b) Loss

c) Enthalpy

d) Entropy

View Answer:

Answer: Option D

Solution:

28. Given a carrier frequency of 100 KHz and a modulating frequency of 5 KHz, the bandwidth of AM transmission is ___ KHz.

a) 5

b) 200

c) 10

d) 20

View Answer:

Answer: Option C

Solution:

29. One of the following transmission impairments is not a problem with a microwave transmission. Which one?

a) Multipath Fading

b) Ducted Signals

c) Rain Attenuations

d) All of the preceding

View Answer:

Answer: Option C

Solution:

30. When the transmitting and receiving antennas are in line of sight of each other, the mode of propagation is _____ wave.

a) Sky

b) Space

c) Surface

d) Ground

View Answer:

Answer: Option B

Solution:

31. Redundancy measures ________.

a) Transmission Rate of a System

b) How likely Symbols are to be Repeated

c) Time Between Failures

d) System Caused Failures

View Answer:

Answer: Option B

Solution:

32. In ionospheric propagation, the nearest distance at which waves return to earth is referred to as ______ distance:

a) LOS

b) Ground Wave

c) Skip

d) Fresnel

View Answer:

Answer: Option C

Solution:

33. What type of cable would you choose if you wanted an inexpensive, long-distance, medium-bandwidth transmission link where several circuits run in parallel?

a) Open Wire

b) Quadded-Exchange Cable

c) Quadded-toll Cable

d) Coaxial Cable

View Answer:

Answer: Option C

Solution:

34. The region in the ionosphere mainly responsible for long distance night time communications is the ________.

a) D-layer

b) E-layer

c) F layer

d) A-layer

View Answer:

Answer: Option C

Solution:

35. An example of bounded medium is _______.

a) Coaxial Cable

b) Waveguide

c) Fiber Optic Cable

d) All of the Preceding

View Answer:

Answer: Option D

Solution:

36. Antenna polarization is determined by______.

a) The direction of the magnetic field vector

b) The direction of the electric field vector

c) The frequency of the radiated wave

d) The direction of the radiated wave

View Answer:

Answer: Option B

Solution:

37. One of the following is not an advantage of coaxial cable for data communications. Which is it?

a) Wide Bandwidth

b) Flexibility of the System Layout

c) Noise Immunity

d) Right-of-way Costs

View Answer:

Answer: Option D

Solution:

38. In a half-wave dipole antenna, maximum radiation occurs:

a) Off the Ends

b) Broadside to the Antenna

c) At 45o angle to the direction of the dipole

d) When end effects are reduced to zero

View Answer:

Answer: Option B

Solution:

39. Coaxial cable has conductors with _____.

a) The same Diameter

b) Common Axis

c) Equal Resistance

d) Both (a) and (c)

View Answer:

Answer: Option B

Solution:

40. At even Fresnel zone radius, the microwave system has a _____.

a) Gain

b) Loss

c) No Gain and No Loss

d) Infinite FSL

View Answer:

Answer: Option B

Solution:

41. Which of the following is not a characteristics of satellite transmission systems?

a) Long signal delays from sender to receiver

b) Affected by weather in the earth’s surface

c) Vulnerable to the right galactic noise levels of space

d) Penetrates ionospheric layers

View Answer:

Answer: Option A

Solution:

42. Fade margin is based from _____ threshold.

a) Noise

b) FM Improvement

c) Absolute

d) Detection

View Answer:

Answer: Option B

Solution:

43. Fiber optic cables operate at frequencies near ______.

a) 20 MHz

b) 200 MHz

c) 2 GHz

d) 800 THz

View Answer:

Answer: Option D

Solution:

44. A method of diversity reception applied to reflective path to reduce fading is ______ diversity.

a) Frequency

b) Space

c) Polarization

d) Angle

View Answer:

Answer: Option B

Solution:

45. The frequency range of piano is from 25 to 8,000 Hertz. What is the range of wavelengths in feet?

a) 45.2 to 0.14125 ft.

b) 142.3 to 163.8 ft.

c) 0.14125 to 45.2 ft.

d) 300 to 3,000 ft.

View Answer:

Answer: Option A

Solution:

46. The amount of attenuation present in a waveguide is due to _____.

a) The air dielectric filling the guide

b) The fine coating of silver inside

c) I2R Losses

d) Losses in the conducting walls of the guide

View Answer:

Answer: Option D

Solution:

47. HF radio waves have how many basic paths leaving the transmitter?

a) Two

b) Four

c) One

d) Many

View Answer:

Answer: Option A

Solution:

48. A material wrapped around the parabolic antenna aperture to eliminate sidelobes interfering nearby microwave stations is called _______.

a) Radome

b) Shield

c) Shroud

d) Dust Cover

View Answer:

Answer: Option C

Solution:

49. If sound waves are converted to electrical waves by a microphone. What is the frequency of the electric current?

a) 3 to 30 MHz

b) 25 to 8,000 Hz

c) 4 to 40 Hz

d) 30 to 3,000 Hz

View Answer:

Answer: Option B

Solution:

50. In a telephone transmitter, conversion of acoustic energy into electric energy is accomplished by means of a varying resistance of the carbon granules. When carbon granules are compressed, the resistance is

a) Decreased

b) Increased

c) The Same

d) None of these

View Answer:

Answer: Option A

Solution:

51. The requirements for successful transmission system using light are

a) Powerful, Reliable Light Source

b) Strong Glass

c) Reliable, high cost transmission medium

d) Power Amplifiers

View Answer:

Answer: Option A

Solution:

52. A loading coil which is a common method to increase subscriber loop length will

a) Reduce Loss

b) Increase Impedance

c) Decrease Velocity of Propagation

d) All of the preceding

View Answer:

Answer: Option D

Solution:

53. For a music lover concert “A” is 440 Hz. If a musical note one octave higher were played, it would be ______ that frequency.

a) One-half

b) One-fourth

c) Double

d) Triple

View Answer:

Answer: Option C

Solution:

54. A loaded telephone cable using AWG # 22, with a spacing between loading coils between loading coils 6,000 feet and having an inductance of 88 mH, is specified as ________.

a) 88 -22B

b) 22-88B

c) H-22-88

d) 22-H-88

View Answer:

Answer: Option D

Solution:

55. Multiple repeaters in communications satellites are known as

a) Transponders

b) Detectors

c) Modulators

d) Stations

View Answer:

Answer: Option A

Solution:

56. In a two-party system, the method of ringing is called _____ frequency.

a) Divided

b) Multi

c) Decimonic

d) Harmonic

View Answer:

Answer: Option A

Solution:

57. In a 220 Hz synthesizer signal, if a note were played one octave below it would be _______.

a) 22 Hz

b) 27.5 Hz

c) 440 Hz

d) 110 Hz

View Answer:

Answer: Option D

Solution:

58. A switching equipment which connects a party to an idle circuit while speech is taking place and disconnects of 800 the party when speech is stopped is called ______.

a) PCM

b) ESS

c) TASI

d) FDM

View Answer:

Answer: Option C

Solution:

59. The loss in signal power as light travels down a fiber is called:

a) Propagation

b) Scattering

c) Absorption

d) Attenuation

View Answer:

Answer: Option D

Solution:

60. A line from the telephone subscriber to the Central Office is called _____.

a) Inter-office Trunk

b) Tie

c) Service Drop Wire

d) Subscriber Loop

View Answer:

Answer: Option D

Solution:

61. The earth’s area or region that the satellite can receive from or transmit to

a) Footprint

b) Primary Area

c) Skip Zone

d) Coverage Area

View Answer:

Answer: Option A

Solution:

62. If the grade of service of a telephone system is indicated as P = 0.005, it means

a) Completed Calls of 5%

b) Lost Calls of 5%

c) Lost Calls of 95%

d) Lost Calls of 105%

View Answer:

Answer: Option B

Solution:

63. When the index of refraction is greater in material 1 than it is in material 2, the velocity of propagation in material 1 compared to material 2 is _____.

a) Equal to or Greater

b) Greater

c) Lesser

d) Equal

View Answer:

Answer: Option C

Solution:

64. During the busy hour in a telephone system, an average of one call out of 100 is lost. The grade of service is approximately:

a) 1.01%

b) 10%

c) 0.10

d) 0.01

View Answer:

Answer: Option D

Solution:

65. Incidentally proposed the geostationary scheme or orbit of the satellite in 1940’s.

a) Arthur Clarke

b) Carl F Gauss

c) Samuel Morse

d) Stephen Gray

View Answer:

Answer: Option A

Solution:

66. A transmission line with a characteristic impedance (Z0) of 300 Ohms is terminated in a resistive load (RL) If by measurement, the minimum and maximum voltages through the load are 12 and 20 microvolts certain respectively, what is the SWR?

a) 1.67

b) 0.6

c) 6.7

d) 0.3

View Answer:

Answer: Option A

Solution:

67. Deposition of dopants on fiber preforms is done by _________.

a) Outside Vapor Deposition

b) Axial Vapor Deposition

c) Inside Vapor Deposition

d) All of the Preceding

View Answer:

Answer: Option D

Solution:

68. A transmission line with a characteristic impedance (Z0) of 300 ohms is terminated in a resistive load (RL) If by measurement, the minimum and maximum voltages through the load are 12 and 20 microvolts, respectively, what are the two possible values of load RL in Ohms?

a) 300 and 600 Ohms

b) 600 and 900 Ohms

c) 150 and 80 Ohms

d) 501 and 180 Ohms

View Answer:

Answer: Option D

Solution:

69. When the satellites are spaced 4o of the 360o complete circle, how many orbital slots are available.

a) 90

b) 85

c) 95

d) 80

View Answer:

Answer: Option A

Solution:

70. A line has characteristic impedance of 1000 /-30° Ohms and is terminated to a load having an impedance of 800 – jl00 Ohms. The line’s SWR and return loss are _______ and ____ respectively.

a) 6.1; 17.62

b) 1.26; 12.76

c) 2.6; 17.26

d) 3.6, 12.76

View Answer:

Answer: Option B

Solution:

71. The core of an optical fiber has_____

a) A lower index of refraction than air

b) A lower index of refraction than the cladding

c) A higher index of refraction than the cladding

d) Both (a) and (b)

View Answer:

Answer: Option C

Solution:

72. In ionospheric propagation, the highest frequency that will be reflected back to earth, if propagated at a certain angle of incidence is called ______.

a) Critical Frequency

b) MUF

c) LUF

d) Cut-off Frequency

View Answer:

Answer: Option B

Solution:

73. Analogous to power dissipation in copper cables _____.

a) Absorption Loss

b) Scattering Losses

c) Modal Dispersion

d) Radiation Losses

View Answer:

Answer: Option A

Solution:

74. Remote users to a LAN can be restricted by _______ Modems

a) Callback

b) Dial-up

c) Asynchronous

d) Synchronous

View Answer:

Answer: Option A

Solution:

75. _____ are the different angles of entry into an optical fiber when the diameter of the core is many times the wavelength of the light transmitted.

a) Emitters

b) Modes

c) Sensors

d) Refraction

View Answer:

Answer: Option B

Solution:

76. AWG 19 copper wire has a diameter of 35.89 mils. The cross-sectional area is ____ circular mils.

a) 35.89

b) 19

c) 1144

d) 1288

View Answer:

Answer: Option D

Solution:

77. It is usually made from a semiconductor material such as aluminum-gallium-arsenide or gallium arsenide. phosphide __________.

a) Light Emitting Diode

b) Injection Laser Diode

c) Positive Intrinsic Diode

d) APD

View Answer:

Answer: Option A

Solution:

78. An AWG 10 wire having a diameter of 0.102 inch has an area of _____ circular mils.

a) 4110

b) 6400

c) 10,400

d) 14,600

View Answer:

Answer: Option C

Solution:

79. In single mode fibers, a large fraction of the power is cultivated in the _________.

a. Sheath

b. Core

c. Cladding

d. Armor

View Answer:

Answer: Option C

Solution:

80. An AM broadcasting station is rated at 5 kilowatts. If the received signals vary as the square root of the radiated power, then how much gain (in dB) would be apparent to a nearby listener if the broadcasting station doubled its power?

a) 3

b) 1.5

c) 6

d) 2.5

View Answer:

Answer: Option B

Solution:

81. A process in which the trapped photons in the active region stimulate free electrons to recombine with holes at a higher than normal energy level as they reflect back and forth.

a) Lasing

b) Emission

c) Photoelectric Effect

d) Detecting

View Answer:

Answer: Option A

Solution:

82. The length of a half-wave dipole for 28 MHz is approximately ______.

a) 17.6 feet

b) 23.6 feet

c) 30.6 feet

d) 34.6 feet

View Answer:

Answer: Option A

Solution:

83. When amplitude modulation is varied to represent information, the method is called _____.

a) PCM

b) PWM

c) PAM

d) PPM

View Answer:

Answer: Option C

Solution:

84. One kilowatt is supplied to a rhombic antenna resulting to 20 microvolts per meter at the receiving station. In order to produce the same field strength at the receiving station, a half-wave antenna, properly oriented and located near the rhombic, must be supplied with 16.6 kilowatts. What is the gain (in dB) of the rhombic referred to isotropic antenna?

a) 12.2

b) 6.5

c) 14.35

d) 10.25

View Answer:

Answer: Option C

Solution:

85. The amount of voltage induced in a wire by an electromagnetic wave is determined by the wave’s

a) Field Strength

b) Direction of Travel

c) Velocity

d) Frequency

View Answer:

Answer: Option A

Solution:

86. The effective area of an isotropic antenna operating on 136 Megahertz is equal to _____ square meters.

a) 2.22

b) 0.39

c) 1.64

d) 2.15

View Answer:

Answer: Option B

Solution:

87. Demultiplexing by a TDM occurs based upon _________.

a) The position of data within a frame

b) The position of a frame within a group of frames

c) The activity of a connected device

d) The priority assigned to a connected device

View Answer:

Answer: Option A

Solution:

88. The effective absorbing area of a half-wave dipole antenna operating on 136 MHz is ________ square meters.

a) 2.03

b) 0.64

c) 1.64

d) 2.15

View Answer:

Answer: Option B

Solution:

89. An antenna supported by insulators appears electrically longer than its physical length due to_____.

a) End Effect

b) Reflection

c) The Ionosphere

d) The Troposphere

View Answer:

Answer: Option A

Solution:

90. If the base station antenna is 100 feet high and the mobile antenna is 6 feet high, the expected unobstructed distance between the 2 stations is about ______ miles.

a) 13

b) 27

c) 17

d) 47

View Answer:

Answer: Option C

Solution:

91. Two state (binary) communications systems are better because

a) They can interface directly with the analog telephone network

b) Interstate cells are less costly

c) The components are simpler, less costly and more reliable

d) People think better in binary

View Answer:

Answer: Option C

Solution:

92. A circuit where transmission is possible in both directions at the same time but not between the same two stations.

a) Half-Duplex

b) Full-Duplex

c) Full/Half duplex

d) Full/Full Duplex

View Answer:

Answer: Option D

Solution:

93. In a half-wave dipole, maximum radiation of electromagnetic energy occurs _____.

a) Broadside to the Antenna

b) Off the ends

c) At 45o angle to the direction of the dipole

d) When the end effects are reduced to zero

View Answer:

Answer: Option A

Solution:

94. A code that uses three unequal lengths, marks dot, dash and space to encode a character.

a) Baudot Code

b) Morse Code

c) ASCII

d) Hollerith

View Answer:

Answer: Option B

Solution:

95. Codes are always _________.

a) Eight bits per Character

b) Either 7 or 8 bits per Character

c) The same in all medium computers

d) Agreed upon in advance between the sender and the Receiver

View Answer:

Answer: Option D

Solution:

96. Which among these codes is 5-bit character code?

a) EBCDIC

b) ASCII

c) Baudot

d) Trellis

View Answer:

Answer: Option C

Solution:

97. An electromagnetic wave consists of ______

a) Both Electric and Magnetic Fields

b) A Magnetic Field only

c) An Electric Field only

d) Non-Magnetic Field only

View Answer:

Answer: Option A

Solution:

98. In data communications, ARQ means _______.

a) Automatic Requisition

b) Automatic Request for Retransmission

c) Automatic Request Code

d) Automatic Request Repeat

View Answer:

Answer: Option B

Solution:

99. The principal difference between batch processing and on-line processing is _____.

a) Telephones are used for batch processing, CRTs are used for on-line processing

b) Transactions are grouped for batch processing; transactions are processed as needed for online processing

c) On-line processing are exclusively used only for ATM banking while batch processing is universal

d) Computer resources are used more effectively for on-line processing

View Answer:

Answer: Option B

Solution:

100. _____ insures that the transmitter and receiver agree on a precise time slot for the occurrence of a bit.

a) Carrier Synchronization

b) Message Synchronization

c) Character Synchronization

d) Clock Synchronization

View Answer:

Answer: Option D

Solution:

Complete List of Communications Engineering Exams: ECE Pre-Board

DOWNLOAD PDF / PRINT
Print Friendly, PDF & Email
Please do Subscribe on YouTube!

P inoyBIX educates thousands of reviewers and students a day in preparation for their board examinations. Also provides professionals with materials for their lectures and practice exams. Help me go forward with the same spirit.

“Will you subscribe today via YOUTUBE?”

Subscribe

Add Comment

PinoyBIX Engineering. © 2014-2021 All Rights Reserved | How to Donate? | Follow me on Blogarama DMCA.com Protection Status
