# Solution: Determine the average current for a load resistance of 200 Ω

#### Problem Statement: Electronic Systems and Design

Thyristors: SCR Problem Solving

An SCR half-wave rectifier has a forward breakdown voltage of 150 V when gate current of 1 mA flows into the gate circuit. If a sinusoidal voltage of 400 V peak is applied, determine the average current for a load resistance of 200 Ω.

A. 0.613 A

B. 12.26 A

C. 0.542 A

D. 1.267 A

The average current for a load resistance of 200 Ω is equal to 0.613 Ampere.
