Multiple choice questions in Transformers and  Impedance Matching

This is the Multiple Choice Questions (MCQs) in Chapter 18: Transformers and Impedance Matching from the book Teach Yourself Electricity and Electronics, 5th edition by Stan Gibilisco. If you are looking for a reviewer in Electronics Engineering this will definitely help you before taking the Board Exam.

Start Practice Exam Test Questions

1. In a step-up transformer:

  • A. The primary impedance is greater than the secondary impedance.
  • B. The secondary winding is right on top of the primary.
  • C. The primary voltage is less than the secondary voltage.
  • D. All of the above.

2. The capacitance between the primary and the secondary windings of a transformer can be minimized by:

  • A. Placing the windings on opposite sides of a toroidal core.
  • B. Winding the secondary right on top of the primary.
  • C. Using the highest possible frequency.
  • D. Using a center tap on the balanced winding.

3. A transformer steps a voltage down from 117 V to 6.00 V. What is its primary-to-secondary turns ratio?

  • A. 1:380.
  • B. 380:1.
  • C. 1:19.5.
  • D. 19.5:1.

4. A step-up transformer has a primary-to-secondary turns ratio of 1:5.00. If 117V RMS appears at the primary, what is the RMS voltage across the secondary?

  • A. 23.4 V.
  • B. 585 V.
  • C. 117 V.
  • D. 2.93 kV.

5. A transformer has a secondary-to-primary turns ratio of 0.167. This transformer is:

  • A. A step-up unit.
  • B. A step-down unit.
  • C. Neither step-up nor step-down.
  • D. A reversible unit.

6. Which of the following is false, concerning air cores versus ferromagnetic cores?

  • A. Air concentrates the magnetic lines of flux.
  • B. Air works at higher frequencies than ferromagnetic.
  • C. Ferromagnetic are lossier than air.
  • D. A ferromagnetic-core unit needs fewer turns of wire than an equivalent air-core unit.

7. Eddy currents cause:

  • A. An increase in efficiency.
  • B. An increase in coupling between windings.
  • C. An increase in core loss.
  • D. An increase in usable frequency range.

8. A transformer has 117 V RMS across its primary and 234 V RMS across its secondary. If this unit is reversed, assuming it can be done without damaging the windings, what will be the voltage at the output?

  • A. 234 V.
  • B. 468 V.
  • C. 117 V.
  • D. 58.5 V.

9. The shell method of transformer winding:

  • A. Provides maximum coupling.
  • B. Minimizes capacitance between windings.
  • C. Withstands more voltage than other winding methods.
  • D. Has windings far apart but along a common axis.

10. Which of these core types, in general, is best if you need a winding inductance of 1.5 H?

  • A. Air core.
  • B. Ferromagnetic solenoid core.
  • C. Ferromagnetic toroid core.
  • D. Ferromagnetic pot core.

11. An advantage of a toroid core over a solenoid core is:

  • A. The toroid works at higher frequencies.
  • B. The toroid confines the magnetic flux.
  • C. The toroid can work for dc as well as for ac.
  • D. It’s easier to wind the turns on a toroid.

12. High voltage is used in long-distance power transmission because:

  • A. It is easier to regulate than low voltage.
  • B. The I2R losses are lower.
  • C. The electromagnetic fields are stronger.
  • D. Smaller transformers can be used.

13. In a household circuit, the 234-V power has:

  • A. One phase.
  • B. Two phases.
  • C. Three phases.
  • D. Four phases.

14. In a transformer, a center tap would probably be found in:

  • A. The primary winding.
  • B. The secondary winding.
  • C. The unbalanced winding.
  • D. The balanced winding.

15. An autotransformer:

  • A. Works automatically.
  • B. Has a center-tapped secondary.
  • C. Has one tapped winding.
  • D. Is useful only for impedance matching.

16. A transformer has a primary-to-secondary turns ratio of 2.00:1. The input impedance is 300 Ω resistive. What is the output impedance?

  • A. 75 Ω
  • B. 150 Ω
  • C. 600 Ω
  • D. 1200 Ω

17. A resistive input impedance of 50 Ω must be matched to a resistive output impedance of 450 Ω. The primary-to-secondary turns ratio of the transformer must be:

  • A. 9.00:1.
  • B. 3.00:1.
  • C. 1:3.00.
  • D. 1:9.00.

18. A quarter-wave matching section has a characteristic impedance of 75.0 Ω. The input impedance is 50.0 Ω resistive. What is the resistive output impedance?

  • A. 150 Ω
  • B. 125 Ω
  • C. 100 Ω
  • D. 113 Ω

19. A resistive impedance of 75 Ω must be matched to a resistive impedance of 300 Ω. A quarter-wave section would need:

  • A. Zo = 188 Ω
  • B. Zo = 150 Ω
  • C. Zo = 225 Ω
  • D. Zo = 375 Ω

20. If there is reactance at the output of an impedance transformer:

  • A. The circuit will not work.
  • B. There will be an impedance mismatch, no matter what the turns ratio of the transformer.
  • C. A center tap must be used at the secondary.
  • D. The turns ratio must be changed to obtain a match.
