Choose the letter of the best answer in each questions.

301. A grinding mill of large diameter with either lumps of ore pebbles or steel balls as crushing bodies the dry lead is air swept remove mesh material.

A. Aerial speed

B. Aero fall mill

C. Aero motor

D. Ball mill

302. A tool – steel cutter used fro – finishing surfaces of angles greater than or less than 90* with its axis of rotation called:

A. Angle cutter

B. Asphalt cutter

C. Circular cutter

D. Helical cutter

303. When installing a new grinding wheel, always use:

A. Blotting paper gaskets on each side of the wheel

B. Copper gasket on each side of the wheel

C. Only the steel washers provided with the machine

D. None of these

304. The tool used to check external pipe threads is called a:

A. plug gage

B. thread gage

C. pitch gage

D. ring gage

305. The tool used to check internal pipe threads is called a:

A. plug gage

B. thread gage

C. pitch gage

D. ring gage

306. The tool used to cut gears is called a:

A. gear cutter

B. gear hob

C. gear center

D. gear threader

307. If use a dry grinding wheel for sharpening tool bits, dip the end of the bit in water frequently to prevent-

A. burning your fingers

B. annealing the cutting edge of the bit

C. hardening of the tip

D. the tip from crystallizing

308. CNC in machine shop means

A. Communication Network Control

B. Computer Network Center

C. Computer Number Control

D. Computer Numerical Control

309. It is the time lost due to breakdowns, waiting for tools, minor accidents etc.

A. Down time

B. Handling time

C. Machining time

D. Set up time

310. What is the necessity of giving tolerance?

A. It saves the labor charges

B. Its saves the material from wastage

C. It saves the time

D. All of these

311. It is done then and there by adjusting or repairing the faults

come in notice during work.

A. Corrective maintenance

B. Predictive maintenance

C. Preventive maintenance

D. Routine maintenance

312. Which statement does NOT belong to the function of bearings?

A. To give free rotation to the shaft

B. To guide the shaft

C. To support the shaft

D. To transmit power

313. A “pillar” file has:

A. One safe edge

B. Three safe edges

C. Two safe edges

D. A or C

314. In general, files are divided into two classes called:

A. Single – cut and double – cut

B. Fine and coarse

C. Rough and smooth

D. Heel and sizes

315. The length of a file is measured from:

A. End to end

B. Point to heel

C. Point to end

D. Heel to end

316. A “pillar” file is used for:

A. Filling slots

B. Filling keyways

C. Filling against a shoulder

D. Any of these

317. A flexible hacksaw blade has a tendency to:

A. Snap easily

B. Buckle or run out of line when too much pressure is applied

C. Cut too fast

D. Cut on a slant

318. Soldering is the process of:

A. Holding two metals together by heating

B. Joining two metals by third soft metal that is applied in a molten state

C. Holding two different kinds of metals together by heating

D. Joining two metals together by heating

319. When soldering, flux is used to;

A. Keep the solder from running off the metal

B. Keep the metal from getting too hot

C. Keep the tip of the soldering iron clean

D. Remove and prevent oxidation of the metals

320. What is used to connect the shaft whose axes are intersecting?

A. Flexible coupling

B. Oldham coupling

C. Rigid coupling

D. Universal coupling

321. It is generally used on high speed with light load because it has point contact.

A. Ball bearing

B. Metal bearing

C. Roller bearing

D. Wood bearing

322. It is generally used on high speed with heavy load because it has line contact.

A. Ball bearing

B. Metal bearing

C. Plastic bearing

D. Roller bearing

323. It is a process of enlarging and smoothening the punched hole by means of tapered drifts of various sizes and shape.

A. Drawing out

B. Drifting

C. Jumping

D. Upsetting

324. It is a set of gears fitted in different position on a plate which are controlled by a lever.

A. Differential gear

B. Gear train

C. Stud gear

D. Tumbler gear

325. An instrument for determining the relative hardness of material by a drop and rebound method.

A. Brinell hardness tester

B. Rockwell hardness tester

C. Scleroscope

D. Universal testing machine

326. An instrument for measuring the degree of surface roughness in micro inches.

A. Caliper

B. Micrometer

C. Profilometer

D. Sclerescope

327. These spindle of the grinding machine on which the wheel is mounted.

A. Arbor

B. Bearing

C. Bushing

D. Fluting

328. A device for holding grinding wheels of special shape or the working piece – being grounded.

A. Chuck

B. Fixtures

C. Head stock

D. Jigs

329. Grinding the grooves of a twist drill or tap.

A. Flaring

B. Fluting

C. Honing

D. Lapping

330. The dulling of the cutting particles of a grinding wheel resulting in a decreased rate of cutting is called

A. fluting

B. Glazing

C. grinding

D. lapping

331. The process of lengthening a piece of stock while the cross-sectional area is being reduced

A. Drawing

B. Honing

C. Tapping

D. Upsetting

332. The major factors, which determined the rpm on milling cutter, are the material being cut and

A. depth of the cutter

B. diameter of cutter

C. number of teeth in cutter

D. time allowed to complete the job

333. Electron beam machining process is quite suitable for a material having

A. high melting point and high thermal conductivity

B. high melting point and low thermal conductivity

C. low melting point and low thermal conductivity

D. low melting point and high thermal conductivity

334. Grinding is what type of operation?

A. Metal finishing operation

B. Metal fusing operation

C. Metal powdering operation

D. metal surfacing operation

335. Grinding is done wherever

A. a large amount of material is to be removed

B. a small amount of material is to be removed

C. high accuracy is required

D. other machining operations can not be carried out

336. Laser beam machining process is used to machine

A. heavier materials

B. lighter materials

C. thicker materials

D. thinner materials

337. A hard grade-grinding wheel is suitable for grinding

A. both hard and soft materials

B. hard materials

C. smooth materials

D. soft materials

338. The usual ratio of forward and return stroke, in quick mechanism of shaping machine is

A. 3:1

B. 3:2

C. 5:2

D. 6:8

339. Solder will not unite with metal surface that has:

A. grease on it

B. dirt on it

B. dirt on it

D. any of these

340. Prepared soldered paste flux is most popular but if you did not have any, you should use:

A. hydrochloric acid

B. sulphuric acid

C. nitric acid

D. any of these

341. Another name for hydrochloric acid is:

A. sulphuric acid

B. muriatic acid

C. nitric acid

D. acetic acid

342. Hard solder is made of:

A. copper and zinc

B. tin and zinc

C. tin and copper

D. tin and lead

343. Soft solder is made of:

A. copper and zinc

B. tin and lead

C. tin and copper

D. tin and zinc

344. Soft solder melts at approximately:

A. 250 deg.

B. 350 deg.

C. 450 deg.

D. 550 deg.

345. The flux usually used for hard solder is:

A. rosin

B. Borax

C. barium

D. alum

346. Which of the following is a boring machine tool used particularly for large work place, types are horizontal and vertical?

A. Boring mill

B. Burrstone mill

C. Cage mill

D. Chile mill

347. A small portable hand drill customarily used by hand setters to drill the holes in breast called

A. spiral drill

B. diamond drill

C. churn drill

D. breast drill

348. A job, which is fixed away from the table, can be machined by

A. running head

B. moving head

C. static head

D. traveling head

349. Shaper tools are made of

A. cast iron

B. high speed steel

C. mild steel

D. wrought iron

350. Refers to the unit can be moved longitudinally along the swivel table and is clamped in position by two bolts one on either side of the base

A. Cross stock

B. Foot stock

C. Head stock

D. Tail Stock
