# Solution: Find the total power drawn by the impedance

#### Problem Statement: Electrical Engineering Professional Subjects

Electric Circuits: AC Circuits Problem Solving

Given three impedances: Z1 = 10 + j0 ohms, Z2 = 3 + j4 ohms and Z3 = 8 โ j6 ohms. Impedance Z2 and Z3 are connected in parallel and the combination is connected in series with impedance Z1 across a 120 V single-phase 60 Hz source. Find the total power drawn by the impedance.

A.ย  1008 W

B.ย  1204 W

C.ย  1038 W

D.ย  1103 W

The total power drawn by the impedance is equal to 1008 Watts.
