Choose the letter of the best answer in each questions.
1. What composes all matter whether a liquid, solid or gas?
a. Atoms
b. Electrons
c. Protons
d. Neutrons
Answer: Option A
Solution:
2. The Piezoelectric effect in a crystal is _____.
a. a voltage developed because of mechanical stress
b. a change in resistance because of temperature
c. a change of frequency because of temperature
d. none of the choices
Answer: Option A
Solution:
3. A unit impulse function on differentiation results in
a. unit doublet
b. unit triplet
c. unit parabolic function
d. unit ramp function
Answer: Option A
Solution:
4. In the JK flip-flop a High on the K input during the clock transition will yield an output of
a. Q=low
b. Q-toggle
c. Q=high
d. not possible to determine
Answer: Option D
Solution:
5. What class of operation has little use in general purpose amplifiers but is used in high frequency oscillators?
a. class A
class AB
c. class B
d. class C
Answer: Option D
Solution:
6. Feedback factor is always
a. less than 1
b. equal to 1
c. more than 1
d. zero
Answer: Option A
Solution:
7. Arrival of a clock signal at the clock inputs of different flip-flops at different times as a result of propagation delays.
a. clock transition
b. buffer address
c. clock skew
d. none of the choices
Answer: Option C
Solution:
8. With double the number of turns by the same length and area, the inductance is
a. the same
B. doubled
c. quartered
d. quadrupled
Answer: Option D
Solution:
9. An ideal op-amp has
a. infinite input and output impedance
b. very low input and output impedance
c. low input impedance and infinite output impedance
d. infinite input impedance and zero output impedance
Answer: Option D
Solution:
10. What is the most important factor of a power transistor?
a. impedance matching
b. output resistance
c. mounting
d. heat dissipation
Answer: Option D
Solution:
11. Which of the following methods can be used for measuring power without using wattmeter?
i. One voltmeter, one ammeter
ii. Two voltmeters, two ammeters
iii. Three voltmeters
iv. Three ammeters
a. i and ii only
b. ii and iv only
c. I and iii only
d. iv only
Answer: Option A
Solution:
12. In a junction FET, the control electrode is usually the:
a. source
b. emitter
c. drain
d. gate
Answer: Option D
Solution:
13. It decreases the ripple voltage in the output of a DC generator and increases the output voltage.
a. interpoles
b. prime mover
c. compensating winding
d. multiple coil armature
Answer: Option D
Solution:
14. A material with a high dielectric constant:
a. acts to increase capacitance per unit volume
b. acts to decrease capacitance per unit volume
c. has no effect on capacitance
d. causes a capacitor to become polarized
Answer: Option A
Solution:
15. A toroidal-core coil:
a. has lower inductance than an air-core coil with the same number of turns
b. is essentially self-shielding
c. works well as a Loop stick antenna
d. is ideal as a transmission-line transformer
Answer: Option B
Solution:
16. The horizontal displacement on an oscilloscope CRT screen is usually measured in
a. frequency per unit division
b. current per unit division
c. time per unit division
d. voltage per unit division
Answer: Option C
Solution:
17. Vidicon and plumbicon operate on the principle of:
a. photoconduction
b. photoemission
c. photovoltaic
d. none of these
Answer: Option A
Solution:
18. If the frequency is greater than the power bandwidth,
a. slew-rate distortion occurs
b. a normal output signal occurs
c. output offset voltage increases
d. distortion may occur
Answer: Option A
Solution:
19. In a boost regulator, the output voltage is filtered with a
a. choke-input filter
b. capacitor-input filter
c. diode
d. voltage divider
Answer: Option B
Solution:
20. An amplifier has the following percent harmonic distortions; D2 = 10%, D3 = 5% and D4 = 1%. What is the amplifier % THD?
a. 5.33%
b. 11.22%
c. 16.0%
d. 22.11%
Answer: Option B
Solution:
21. Magnetic amplifiers are used for
a. voltage amplification
b. power amplification
c. current amplification
d. frequency amplification
Answer: Option B
Solution:
22. A dynamic memory generally contains ________.
a. row and column decoders
b. row decoders
c. no decoders
d. column decoders
Answer: Option A
Solution:
23. At dc, the reactance of a capacitor
a. is zero, in theory
b. is very small negatively
c. is very small positively
d. is negatively infinite, in theory
Answer: Option D
Solution:
24. In a dry cell, what will happen to the internal resistance as it aged?
a. decrease
b. increase
c. remains constant
d. decreases or increases, depends on the chemical composition
Answer: Option B
Solution:
25. Meters built into electrical and electronic devices used to monitor the operation of the devices.
a. Imbedded meters
b. Built-in meters
c. In-circuit meters
d. Metering devices
Answer: Option C
Solution:
26. Syntax checking or a program is done by another program in the computer is called
a. debugger
b. coder
c. compiler
d. processor
Answer: Option C
Solution:
27. A first-order active-filter stage has
a. one capacitor
b. two op amps
c. three resistors
d. a high Q
Answer: Option A
Solution:
28. The magnetic field of a bar magnet most closely resembles the magnetic field of
a. a horseshoe magnet
b. a straight current-carrying wire
c. a stream of electrons moving parallel to one another
d. a current-carrying wire loop
Answer: Option D
Solution:
29. An amplifier with a negative-feedback path at midband frequencies
a. Cannot oscillate because of the negative feedback
b. Can easily oscillate at higher frequencies
c. Will have magnetic oscillations
d. Will have a phase shift of 270° if uncompensated
Answer: Option A
Solution:
30. Which of the following is NOT one of the three distinct regions in the characteristic curve of a diode?
a. forward bias region
b. reverse bias region
c. breakdown region
d. saturation region
Answer: Option D
Solution:
31. Calculate the ripple voltage of a capacitor filter for a peak rectified voltage of 30 V, capacitor C = 100 μF, and a load current of 50 mA.
a. 3.21%
b. 2.10%
c. 5.85%
d. 4.30%
Answer: Option D
Solution:
32. The basic memory cell of dynamic RAM consists of
a. a capacitance
b. a transistor
c. a flip-flop
d. a transistor acting as a capacitor
Answer: Option D
Solution:
33. The zener current in a zener follower is
a. equal to the output current
b. smaller than the output current
c. larger than the output current
d. prone to thermal runaway
Answer: Option B
Solution:
34. A control system in which the output is related to the input by device parameters only.
a. Open-loop control system
b. Closed-loop control system
c. Servomechanism
d. Feedback Control system
Answer: Option A
Solution:
35. The two general types of heating methods in industrial electronics are ________.
a. frequency and induction heating
b. induction and dielectric heating
c. coil and dielectric heating
d. coil and frequency heating
Answer: Option A
Solution:
36. To reduce the distortion in a CE amplifier, reduce the
a. dc emitter current
b. base-emitter voltage
c. collector current
d. ac base voltage
Answer: Option D
Solution:
37. A relay is connected into a circuit so that a device gets a signal only when the relay coil carries current. The relay is probably
a. An AC relay
b. A DC relay
c. Normally closed
d. Normally open
Answer: Option D
Solution:
38. Electron mobility property of silicon at 300 K is approximately equal to ___________ m2/ V-s
a. 1.1
b. 0.135
c. 0.048
d. 45
Answer: Option B
Solution:
39. A magnetic drum:
a. is similar to a drum in the orchestra
b. stores data in grooves that run in circles around the drum head
c. is a cylinder with data recording tracks running around its circumference
d. stores data in grooves running lengthwise along the drum
Answer: Option C
Solution:
40. Most of the digital computer do not have floating-point hardware because
a. floating point hardware is costly
b. it is slower than software
c. it is not possible to perform floating point addition by hardware
d. of no specific reason
Answer: Option A
Solution:
41. A data sheet gives these JFET values: IDSS = 20 mA and pinch-off voltage is 5 volts. What is the gate-source cut-off voltage?
a. 15 volts
b. 10 volts
c. -5 volts
d. 5 volts
Answer: Option C
Solution:
42. If the two supply voltages are plus and minus 15 V, the MPP value of an op amp is closest to
a. 0
b. +15 V
c. -15 V
d. 30 V
Answer: Option D
Solution:
43. If the transient during switching of a power supply are to be studied, which oscilloscope will be preferred?
a. An ordinary oscilloscope with high frequency sweep generator
b. Dual beam oscilloscope
c. Dual storage oscilloscope
d. Storage oscilloscope
Answer: Option D
Solution:
44. The dropout voltage of standard monolithic linear regulators is closest to
a. 0.3 V
b. 0.7 V
c. 2 V
d. 3.1 V
Answer: Option C
Solution:
45. Convert (614)8 to decimal.
a. 400
b. 384
c. 392
d. 396
Answer: Option D
Solution:
46. The output waveform of a 555 timer is
a. sinusoidal
b. triangular
c. rectangular
d. elliptical
Answer: Option C
Solution:
47. The purpose of a pentavalent impurity is to
a. reduce the conductivity of silicon
b. increase the number of holes
c. increase the number of free electrons
d. create minority carriers
Answer: Option C
Solution:
48. What happens if the input capacitor of a transistor of a transistor amplifier is short-circuited?
a. biasing conditions will change
b. transistor will be destroyed
c. signal will not reach the base
d. biasing will stabilize
Answer: Option A
Solution:
49. Binary hardware computes division as:
a. addition
b. multiplication
c. subtraction
d. none of these
Answer: Option C
Solution:
50. With both bases grounded, the only offset that produces an error is the
a. input offset current
b. input bias current
c. input offset voltage
d. Beta
Answer: Option C
Solution:
51. Suppose an ac signal has a frequency of 1770 Hz. What is its angular frequency?
a. 1770 rad/s
b. 11,120 rad/s
c. 282 rad/s
d. impossible to determine from the data given
Answer: Option B
Solution:
52. X-rays are produced by
1. Bombarding metallic targets with high speed electrons
2. Decelerating fast moving electrons
3. Accelerating electrons to high speeds
4. Heating a filament to high temperature
a. 1 and 2 only
b. 2 and 4 only
c. 3 and 4 only
d. 1 and 4 only
Answer: Option A
Solution:
53. The sections of a basic isolation amplifier are
a. copper strips
b. transformers
c. microwave links
d. current loops
Answer: Option B
Solution:
54. Which of the following is a dc bridge that is very useful for making extremely accurate voltage measurements?
a. Wheatstone bridge
b. Potentiometer bridge
c. Kelvin bridge
d. Owen bridge
Answer: Option B
Solution:
55. If the net reactance in a series coil-capacitor circuit is zero at frequency f, what will be the nature of the reactance at frequency 2f?
a. zero
b. inductive
c. capacitive
d. resistive
Answer: Option B
Solution:
56. A converter that changes ac-voltage to ac-voltage level
a. inverter
b. cycloconverter
c. dc-converter
d. ac converter
Answer: Option D
Solution:
57. What is the approximate short circuit current output of 741 op amp?
a. 15 mA
b. 30 mA
c. 25 mA
d. 35 mA
Answer: Option C
Solution:
58. Calculate the CMRR of a voltage follower whose common mode gain is 0.005.
a. 0.005
b. -46 dB
c. 1
d. 200
Answer: Option D
Solution:
59. Nodal analysis is best used together with
a. KVL
b. VDT
c. KCL
d. CDT
Answer: Option C
Solution:
60. A graph which shows the relationship between the armatures generated emf and the field excitation in terms of field current.
a. magnetization curve
b. hysteresis curve
c. load curve
d. regulation curve
Answer: Option A
Solution:
61. It is a robot structure wherein the body can rotate horizontally, and the arm can move vertically and horizontally.
a. polar structure
b. pivotal
c. cylindrical structure
d. roborat
Answer: Option C
Solution:
62. Series motors are also called _____.
a. synchronous motors
b. dc motors
c. induction motors
d. universal motors
Answer: Option D
Solution:
63. A single digital word storage device is called:
a. gate
b. clock
c. timer
d. register
Answer: Option D
Solution:
64. Which of the following is a good use, or place, for a wire wound resistor?
a. To dissipate a large amount of dc power
b. In the input of a radio-frequency amplifier
c. In the output of a radio-frequency amplifier
d. In an antenna, to limit the transmitter power
Answer: Option A
Solution:
65. Suppose that two capacitors are in parallel. Their values are 47.0 pF and 470.0 pF. What is the net capacitance of this combination?
a. 43 pF
b. 517 pF
c. 517 μF
d. 470 μF
Answer: Option B
Solution:
66.When Q factor of a circuit is high, then
a. Power factor of the circuit is high
b. Bandwidth is large
c. Impedance of the circuit is high
d. None of these
Answer: Option D
Solution:
67. Which of the items below is not true with a of a transistor?
a. it is the current gain of a common-base configuration
b. it is the ratio of the change in collector current to the change in emitter current
c. it is usually having a value of unity in some approximations
d. it is the ratio of the change in collector current to the change in base current
Answer: Option D
Solution:
68. A program loop:
a. is an input channel
b. is used to avoid repetition of a series of operation
c. is a circuit within a storage unit
d. is a programmed instruction that causes a series of operations to be repeated
Answer: Option D
Solution:
69. The configuration noted for its stability in RF power amplifiers
a. common emitter circuit
b. common base circuit
c. common collector circuit
d. emitter follower circuit
Answer: Option B
Solution:
70. A second order system exhibits 100% overshoot. Its damping coefficient is
a. equal to 0
b. equal to 1
c. less than 1
d. greater than 1
Answer: Option A
Solution:
71. A rule-based system is also known as
a. a logic gate
b. an expert system
c. a back-pressure sensor
d. a telechir
Answer: Option B
Solution:
72. Which of the following is not a characteristic of CMOS chips?
a. Sensitivity to damage by electrostatic discharge
b. Low current demand
c. Ability to work at high speed
d. Ability to handle extremely high power
Answer: Option D
Solution:
73. What will happen to the susceptance of a capacitor if the frequency is doubled and all other factor constant?
a. It will decrease to half its former value.
b. It will not change
c. It will double
d. It will quadruple
Answer: Option C
Solution:
74. A ferromagnetic core is placed in an inductor mainly to
a. Increase the current carrying capacity
b. Increase the inductance
c. Limit the current
d. Reduce the inductance
Answer: Option B
Solution:
75. In an RC circuit, as the ratio Xc/R approaches zero, the phase angle
a. approaches -90 degrees
b. approaches zero degree
c. stays the same
d. cannot be found
Answer: Option B
Solution:
76. An autotransformer
a. can be adjusted automatically
b. has a center-tapped secondary
c. consists of a single tapped winding
d. is useful only for impedance matching
Answer: Option C
Solution:
77. Quartz crystal is the most commonly used in crystal oscillators because
a. it is easily available
b. it has superior electrical properties
c. it is quite expensive
d. it is very rugged
Answer: Option B
Solution:
78. A robot, car or truck can best keep itself traveling down a specific lane of traffic by means of
a. stereoscopic machine hearing
b. epipolar navigation
c. edge detection
d. proximity sensing
Answer: Option C
Solution:
79. Plastic dual in-line for insertion into sockets has a package suffix code of
a. N
b. P
c. N and P
d. J
Answer: Option C
Solution:
80. Calculate the permittivity of a material with relative permittivity of 5.
a. 8.854 x 10-11 F/m
b. 1/36π x 10-9 F/m
c. 4.42 x 10-11 F/m
d. 8.854 x 10-12 F/m
Answer: Option C
Solution:
81. What is the only input combination that will produce a high at the output of a five-input AND gate?
a. At least one low input
b. At least one high input
c. All inputs should be low
d. All inputs should be high
Answer: Option D
Solution:
82. The property of a material which opposes the creation of the magnetic flux.
a. elastance
b. permeance
c. susceptance
d. reluctance
Answer: Option D
Solution:
83. The ability of a tuned circuit to maintain oscillation.
a. Barkhaussen effect
b. Edison current
c. Flywheel effect
d. Tuned effect
Answer: Option C
Solution:
84. A high power, low frequency diode is normally _____ than a low power, high frequency diode.
a. heavier
b. smoother
c. larger
d. smaller
Answer: Option C
Solution:
85. Find the BCD equivalent of 1981 (binary code):
a. 000011110001
b. 11110011100
c. 110011000001
d. none of these
Answer: Option D
Solution:
86. The input impedance of a CRO is nearly
a. zero
b. around 10 ohms
c. around 100 ohms
d. around one megaohm
Answer: Option D
Solution:
87. Determine the force in Newton between 4 μC charges separated by 0.1 meter in air.
a. 1.44 N
b. 14.4 N
c. 144 N
d. 1440 N
Answer: Option B
Solution:
88. A crystal diode can be used as a rectifier because it offers _________.
a. low resistance in both directions
b. high resistance in one direction and low resistance in the other direction
c. high resistance in both directions
d. none of these
Answer: Option B
Solution:
89. Material usually used as gate of MOS for IC.
a. monocrystalline silicon
b. gold
c. polysilicon
d. platinum
Answer: Option C
Solution:
90. When a charge builds up without a flow of current, the charge is said to be:
a. ionizing
b. atomic
c. molecular
d. static
Answer: Option D
Solution:
91. As the frequency of a wave gets lower, all other things being equal, the value of Xc for a capacitor
a. increases negatively
b. decrease negatively
c. does not change
d. depends on the current
Answer: Option A
Solution:
92. A triangular wave exhibits
a. an instantaneous rise and a defined decay
b. a defined rise and an instantaneous decay
c. a defined rise and a defined decay, and the two are equal.
d. an instantaneous rise and an instantaneous decay
Answer: Option C
Solution:
93. Determine the ampere-turns when a 10 V battery is connected across a solenoid having 100 turns and a resistance of 5 ohms.
a. 50 At
b. 100 At
c. 200 At
d. 1,000 At
Answer: Option C
Solution:
94. In the derivative error compression
a. damping decreases and settling time decreases
b. damping increases and settling time increases
c. damping decreases and settling time increases
d. damping increases and settling time decreases
Answer: Option D
Solution:
95. Joule / Coulomb is the unit of
a. Electric filed potential
b. Potential
c. Charge
d. none of these
Answer: Option B
Solution:
96. Two sine waves are in phase opposition. Wave X has a peak amplitude of 4 V and wave Y has a peak amplitude of 8 V. The resultant has a peak amplitude of:
a. 4 V, in phase with the composites
b. 4 V, out of phase with the composites
c. 4 V, in phase with wave X
d. 4 V, in phase with wave Y
Answer: Option D
Solution:
97. How will you handle unused inputs in a logic gate/logic IC?
a. leave them floating
b. pull them down
c. pull them up
d. pull them down or up, depending on circuit function
Answer: Option D
Solution:
98. A laminated iron core has reduced eddy current losses because
a. the laminations are stacked vertically
b. the laminations are insulated from each other
c. the magnetic flux is concentrated in the air gap of the core
d. more wire can be used with less dc resistance in the coil
Answer: Option B
Solution:
99. If a magnetic flux occurs across 100 turns at a rate of 2 Wb/sec. What is the induced voltage as per Faraday’s law?
a. 100 V
b. 200 V
c. 400 V
d. 800 V
Answer: Option B
Solution:
100. In CRT aquadag carries
a. aqueous solution of graphite
b. sweep voltage
c. secondary emission electrons
d. none of these
Answer: Option A
Solution:
Complete List of Electronics Engineering Pre-Board Exams
P inoyBIX educates thousands of reviewers and students a day in preparation for their board examinations. Also provides professionals with materials for their lectures and practice exams. Help me go forward with the same spirit.
“Will you subscribe today via YOUTUBE?”
