This is the Multiple Choice Questions (MCQs) in Chapter 20: How Diodes Are Used from the book Teach Yourself Electricity and Electronics, 5th edition by Stan Gibilisco. If you are looking for a reviewer in Electronics Engineering this will definitely help you before taking the Board Exam.

Start Practice Exam Test Questions

Gibilisco: MCQ in Introduction to Semiconductors | ECE Board Exam

Choose the letter of the best answer in each questions.

1. When a diode is forward-biased, the anode:

A. Is negative relative to the cathode.

B. Is positive relative to the cathode.

C. Is at the same voltage as the cathode.

D. Alternates between positive and negative relative to the cathode.

View Answer:

Answer: Option B

Solution:

2. If ac is applied to a diode, and the peak ac voltage never exceeds the avalanche voltage, then the output is:

A. Ac with half the frequency of the input.

B. Ac with the same frequency as the input.

C. Ac with twice the frequency of the input.

D. None of the above.

View Answer:

Answer: Option D

Solution:

3. A crystal set:

A. Can be used to transmit radio signals.

B. Requires a battery with long life.

C. Requires no battery.

D. Is useful for rectifying 60-Hz ac.

View Answer:

Answer: Option C

Solution:

4. A diode detector:

A. Is used in power supplies.

B. Is employed in some radio receivers.

C. Is used commonly in high-power radio transmitters.

D. Changes dc into ac.

View Answer:

Answer: Option B

Solution:

5. If the output wave in a circuit has the same shape as the input wave, then:

A. The circuit is linear.

B. The circuit is said to be detecting.

C. The circuit is a mixer.

D. The circuit is a rectifier.

View Answer:

Answer: Option A

Solution:

6. The two input frequencies of a mixer circuit are 3.522 MHz and 3.977 MHz. Which of the following frequencies might be used at the output?

A. 455 kHz.

B. 886 kHz.

C. 14.00 MHz.

D. 1.129 MHz.

View Answer:

Answer: Option A

Solution:

7. A time-domain display might be found in:

A. An ammeter.

B. A spectrum analyzer.

C. A digital voltmeter.

D. An oscilloscope.

View Answer:

Answer: Option D

Solution:

8. Zener voltage is also known as:

A. Forward breakover voltage.

B. Peak forward voltage.

C. Avalanche voltage.

D. Reverse bias.

View Answer:

Answer: Option C

Solution:

9. The forward breakover voltage of a silicon diode is:

A. About 0.3 V.

B. About 0.6 V.

C. About 1.0 V.

D. Dependent on the method of manufacture.

View Answer:

Answer: Option B

Solution:

10. A diode audio limiter circuit:

A. Is useful for voltage regulation.

B. Always uses Zener diodes.

C. Rectifies the audio to reduce distortion.

D. Can cause objectionable signal distortion.

View Answer:

Answer: Option D

Solution:

11. The capacitance of a varactor varies with:

A. Forward voltage.

B. Reverse voltage.

C. Avalanche voltage.

D. Forward breakover voltage.

View Answer:

Answer: Option B

Solution:

12. The purpose of the I layer in a PIN diode is to:

A. Minimize the diode capacitance.

B. Optimize the avalanche voltage.

C. Reduce the forward breakover voltage.

D. Increase the current through the diode.

View Answer:

Answer: Option A

Solution:

13. Which of these diode types might be found in the oscillator circuit of a

microwave radio transmitter?

A. A rectifier diode.

B. A cat whisker.

C. An IMPATT diode.

D. None of the above.

View Answer:

Answer: Option C

Solution:

14. A Gunnplexer can be used as a:

A. Communications device.

B. Radio detector.

C. Rectifier.

D. Signal mixer.

View Answer:

Answer: Option A

Solution:

15. The most likely place you would find an LED would be:

A. In a rectifier circuit.

B. In a mixer circuit.

C. In a digital frequency display.

D. In an oscillator circuit.

View Answer:

Answer: Option C

Solution:

16. Coherent radiation is produced by a:

A. Gunn diode.

B. Varactor diode.

C. Rectifier diode.

D. Laser diode.

View Answer:

Answer: Option D

Solution:

17. You want a circuit to be stable with a variety of amplifier impedance

conditions. You might consider a coupler using:

A. A Gunn diode.

B. An optoisolator.

C. A photovoltaic cell.

D. A laser diode.

View Answer:

Answer: Option B

Solution:

18. The power from a solar panel depends on all of the following except:

A. The operating frequency of the panel.

B. The total surface area of the panel.

C. The number of cells in the panel.

D. The intensity of the light.

View Answer:

Answer: Option A

Solution:

19. Emission of energy in an IRED is caused by:

A. High-frequency radio waves.

B. Rectification.

C. Electron energy-level changes.

D. None of the above.

View Answer:

Answer: Option C

Solution:

20. A photodiode, when not used as a photovoltaic cell, has:

A. Reverse bias.

B. No bias.

C. Forward bias.

D. Negative resistance.

View Answer:

Answer: Option A

Solution:
